Subaru Sambar VII (2012-2024) mobile device wireless charger module Wiring diagram

A/T ACC VOLT APO 1/ LTR FUSE APO 2 FUSE APO FUSE BLK WIRE BODY CONTROL MODULE CENTER CONSOLE 1 ACCESSORY POWER RECEPTACLE CENTER CONSOLE 2 ACCESSORY POWER RECEPTACLE CIGARETTE LIGHTER RECEPTACLE CREW CAB DLIS FUSE FROM BODY CONTROL MODULE (DIAGRAM 4 OF 4) FROM IGNITION MAIN RELAY (DIAGRAM 3 OF 4) FROM INSTRUMENT PANEL FUSE BLOCK (DIAGRAM 4 OF 4) FRONT VIEW CAMERA MODULE FRT CAMERA FUSE FUSE 40 GRY/VIO WIRE IGN KEY RES SIG IGNITION SWITCH INSTRUMENT PANEL FUSE BLOCK KEY-IN IGNITION SWITCH LT GRN/VIO WIRE M/T MOBILE DEVICE WIRELESS CHARGER MODULE OFF OFF/RUN/CRANK VOLT PASSENGER WINDOW SWITCH PRNDL FUSE RAP RLY COIL CTRL RED/LT BLU WIRE RED/LT GRN WIRE RED/WHT WIRE RETAINED ACCESSORY POWER RELAY RIGHT REAR WINDOW SWITCH RT PWR WNDW FUSE RUN WIRE RUN/CRANK RLY COIL CTRL TO IGNITION SWITCH (DIAGRAM 4 OF 4) TO INSTRUMENT PANEL FUSE BLOCK (DIAGRAM 3 OF 4) TO INSTRUMENT PANEL FUSE BLOCK (DIAGRAM 4 OF 4) TO UNDERHOOD FUSE BLOCK (DIAGRAM 2 OF 4) TRANSMISSION SHIFT LEVER POSITION INDICATOR VIO WIRE VIO/BLK WIRE VIO/YEL WIRE W/ ACCESSORY SMOKERS PACKAGE W/O ACCESSORY SMOKERS PACKAGE W/ RETAINED ACCESSORY POWER RELAY W/O RETAINED ACCESSORY POWER RELAY WHT/BLK WIRE WHT/VIO WIRE
