Subaru Outback BT facelift (2022-2024) steering control module Wiring diagrams
This page contains all the electrical diagrams for the component. steering control module, in which he is found in the car Subaru Outback BT facelift (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
steering control module wiring diagram (1 of 2)
A/C CONTROL MODULE
BLK WIRE
CENTRAL GATEWAY CONTROL MODULE
DC/DC CONVERTER 2
FRONT ACCESSORY POWER SUPPLY SOCKET
FRONT POWER WINDOW SUB SWITCH
GB-1 (RIGHT KICK PANEL)
GRY WIRE
HAZARD SWITCH
HEATER
LEFT FRONT DOOR LOCK ACTUATOR
LEFT FRONT DOOR STEP LIGHT
LEFT OUTER MIRROR ASSEMBLY
LEFT OUTER MIRROR CONTROL MODULE
LEFT VANITY MIRROR LIGHT
NCA WIRE
OP CONNECTOR (REAR VIEW MIRROR)
OP CONNECTOR (WIRELESS CHARGING)
PASSENGERS DOOR LOCK SWITCH
POWER TRANSISTOR
REAR ACCESSORY POWER SUPPLY SOCKET (CONSOLE)
REAR VIEW MIRROR)
REMOTE CONTROL MIRROR SWITCH
RIGHT FRONT DOOR LOCK ACTUATOR
RIGHT FRONT DOOR STEP LIGHT
RIGHT FRONT POWER WINDOW MOTOR
RIGHT OUTER MIRROR ASSEMBLY
RIGHT OUTER MIRROR CONTROL MODULE
RIGHT VANITY MIRROR LIGHT
ROLL CONNECTOR
ROOM LIGHT
SEAT POSITION MEMORY SWITCH
SPOT MAP LIGHT
STEERING COLUMN)
STEERING CONTROL MODULE
STEERING WHEEL)
SUNROOF SWITCH (SLIDE, TILT)
SUNROOF UNIT
TELEMATICS BUTTON
TO GROUND GB-2 (DIAGRAM 5 OF 6)
USB POWER SUPPLY (CONSOLE)
W/ AUDIO AMPLIFIER
W/ BSD/ RCTA
W/ MEMORY
W/ MIRROR TURN
W/O MEMORY
WHT WIRE
Go to component -> Ground distribution circuit (4 of 6) -> STEERING CONTROL MODULE
steering control module wiring diagram (2 of 2)
ACCESSORY RELAY
BLK WIRE
BLU WIRE
DIMMER
ELEMENT
FUSE 35
FUSE 9
FUSE, RELAY BOX (F/B)
GB-1
GB-2
HOT AT ALL TIMES
HOT W/ ACCESSORY RELAY-1 ENERGIZED
MAIN FUSE BOX (M/B)
NCA WIRE
ONE STEP
RED WIRE
ROLL CONNECTOR
STEERING COLUMN)
STEERING CONTROL MODULE
STEERING HEATER SWITCH
STEERING WHEEL)
THERMISTOR
THERMOSTAT
VIO WIRE
WHT WIRE
Go to component -> Heated steering wheel circuit -> STEERING CONTROL MODULE
