Car Wiring Diagrams for Reverse automatic braking system circuit for Subaru Outback BS facelift (2017-2021)

BLK WIRE BLU WIRE BRN WIRE CIRCUIT COMBINATION METER COMPUTER DATA LINES SYSTEM DOWN SWITCH DRIVE FUSE 14 FUSE 15 FUSE 5 FUSE, RELAY BOX (F/B) GB-3 GB-8 GRN WIRE GRN/YEL WIRE GRY WIRE HIGH SPEED CAN TRANSCEIVER HOT AT ALL TIMES HOT W/ IG 2 RELAY ENERGIZED I/SET SWITCH LEFT CORNER SONAR SENSOR LEFT INNER SONAR SENSOR LT BLU WIRE LT GRN WIRE MICROCOMPUTER NCA WIRE ORG/ WIRE PNK WIRE POWER DISTRIBUTION SYSTEM RED WIRE REVERSE AUTOMATIC BRAKING CONTROL MODULE RIGHT CORNER SONAR SENSOR RIGHT INNER SONAR SENSOR ROLL CONNECTOR SPEAKER STEERING COLUMN) STEERING SWITCH STEREO CAMERA UP SWITCH VIO WIRE WHT WIRE YEL WIRE
