Subaru Outback BS facelift (2017-2021) left outer mirror assembly Wiring diagram
This page shows the only wiring diagram for the component.left outer mirror assembly, which is found in the car Subaru Outback BS facelift (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left outer mirror assembly (11 of 11)
A/C CONTROL PANEL
BLK WIRE
BLU WIRE
BODY INTEGRATED UNIT
DATA LINK CONNECTOR
FROM FUSE 19 (DIAGRAM 4 OF 8)
FROM FUSE, RELAY BOX (F/B) (DIAGRAM 5 OF 8)
FROM MAIN FUSE BOX (M/B) (DIAGRAM 1 OF 8)
FUSE 26
FUSE, RELAY BOX (F/B)
GB-1
GRN WIRE
HIGH BEAM ASSIST MODULE
IG 1 RELAY
KEYLESS ACCESS CONTROL MODULE
LEFT DOOR POCKET LIGHT
LEFT DOOR STEP LIGHT
LEFT OUTER MIRROR ASSEMBLY
LEFT VANITY MIRROR ILLUMINATION LIGHT
LT BLU WIRE
LT GRN WIRE
LUGGAGE ROOM LIGHT
ORG/ WIRE
PNK WIRE
POWER REAR GATE INNER SWITCH
PUSH BUTTON IGNITION SWITCH
REAR VIEW MIRROR)
RED WIRE
REMOTE ENGINE START CONTROL MODULE
REMOTE ENGINE START CONTROL MODULE CONNECTOR
RIGHT DOOR POCKET LIGHT
RIGHT DOOR STEP LIGHT
RIGHT OUTER MIRROR ASSEMBLY
RIGHT VANITY MIRROR ILLUMINATION LIGHT
ROOM LIGHT
SPOT MAP LIGHT
STARTER CUT RELAY
STOP LIGHT, BRAKE SWITCH
TAN WIRE
TO FUSE, RELAY BOX (F/B) (DIAGRAM 1 OF 8)
TPMS CONTROL MODULE
TPMS, KEYLESS ENTRY CONTROL MODULE
TRUNK ROOM LIGHT
W/ POWER REAR GATE SEDAN W/O POWER REAR GATE WAGON W/O POWER REAR GATE
W/O COMPASS
WARNING BOX
WHT WIRE
WIPER DEICER RELAY
Go to component -> Power distribution circuit (6 of 8) -> LEFT OUTER MIRROR ASSEMBLY
