Subaru Outback BS facelift (2017-2021) hill hold switch Wiring diagrams

ABS IND. AUDIO (W/O NAVIGATION) NAVIGATION UNIT (W/ NAVIGATION) BLK WIRE BLU WIRE BRAKE FLUID BRN WIRE COMBINATION METER COMPUTER DATA LINES SYSTEM DRIVE CIRCUIT EPB CONTROL SWITCH EPB ON IND FUSE 10 FUSE 14 FUSE 15 FUSE 3 FUSE, RELAY BOX (F/B) GB-3 (LEFT KICK PANEL) GRN WIRE GRY WIRE HIGH SPEED CAN TRANSCEIVER HILL HOLD ON HILL HOLD SWITCH HOT AT ALL TIMES HOT W/ IG 1 RELAY ENERGIZED HOT W/ IG 2 RELAY ENERGIZED IND LEVEL IND LOCK LT GRN WIRE MICROCOMPUTER PARKING BRAKE PNK WIRE POWER SUPPLY CIRCUIT RED WIRE RELEASE STEERING ANGLE SENSOR STEERING COLUMN) VDC OFF IND VDC OPERATION VDC WARNING VIO WIRE WHT WIRE YEL WIRE

A/C CONTROL PANEL BLK WIRE BLU WIRE BRN WIRE BSD/RCTA OFF SWITCH EPB CONTROL SWITCH FUSE 14 FUSE 15 FUSE, RELAY BOX (F/B) GB-1 GLOVE BOX ILLUMINATION LIGHT GRN WIRE GRY WIRE HAZARD SWITCH HILL HOLD SWITCH HOT AT ALL TIMES HOT W/ IG 2 RELAY ENERGIZED LANE DEPARTURE WARNING OFF SWITCH LEFT REAR SEAT HEATER SWITCH LT GRN WIRE NCA WIRE ORG/ WIRE PNK WIRE POCKET LIGHT PRE-COLLISION BRAKE OFF SWITCH RED WIRE RIGHT REAR SEAT HEATER SWITCH ROLL CONNECTOR SATELLITE SWITCH SELECT LEVER SPOT MAP LIGHT STEERING COLUMN) STEERING HEATER SWITCH STEERING SWITCH (IF EQUIPPED) TELEMATICS BUTTON VIO WIRE W/ EYESIGHT W/ TELEMATICS W/O EYESIGHT W/O REAR SEAT HEATER W/O TELEMATICS W/O X MODE WHT WIRE X MODE SWITCH YEL WIRE

6.2 INCH DISPLAY AUDIO (W/O NAVIGATION) NAVIGATION UNIT (W/ NAVIGATION) BLK WIRE BLK/GRN WIRE BLU WIRE BRAKE FLUID LEVEL SWITCH (BRAKE MASTER CYLINDER) BRN WIRE BRN/YEL WIRE COMBINATION METER COMPUTER DATA LINES SYSTEM DRIVE CIRCUIT EPB CONTROL SWITCH EPB ON IND EPB WARNING/ BRAKE FLUID LEVEL IND FUSE 10 FUSE 14 FUSE 15 FUSE 3 FUSE, RELAY BOX (F/B) GB-3 GRN WIRE GRY WIRE HIGH SPEED CAN TRANSCEIVER HILL HOLD ON IND HILL HOLD SWITCH HOT AT ALL TIMES HOT W/ IG 1 RELAY ENERGIZED HOT W/ IG 2 RELAY ENERGIZED ILL LOCK LT GRN WIRE LT GRN/RED WIRE MICROCOMPUTER PNK WIRE PNK/GRN WIRE POWER SUPPLY CIRCUIT RED WIRE RELEASE VDC CONTROL MODULE VIO WIRE WHT WIRE WHT/VIO WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/WHT WIRE

2.5L 2.5L 3.6L 3.6L A/C CONTROL MODULE A/C CONTROL PANEL ACCESSORY RELAY 1 AIR BAG CONTROL MODULE AUDIO AUDIO AMPLIFIER AUTO HEADLIGHT BEAM LEVELER CONTROL MODULE AUX INPUT TERMINAL BLK WIRE BLU WIRE BODY INTEGRATED UNIT BRN WIRE COMBINATION METER DATA COMMUNICATION MODULE DOOR LOCK BACKUP UNIT ECM, TCM FROM ACCESSORY RELAY 2 (DIAGRAM 4 OF 8) FROM FUSE 19 (DIAGRAM 4 OF 8) FROM IG 1 RELAY (DIAGRAM 4 OF 8) FROM IGNITION SWITCH (DIAGRAM 1 OF 8) FROM MAIN FUSE BOX (M/B) (DIAGRAM 2 OF 8) FUEL PUMP RELAY FUSE 10 FUSE 13 FUSE 15 FUSE 18 FUSE 20 FUSE 23 FUSE 3 FUSE 4 FUSE 5 FUSE 9 FUSE, RELAY BOX (F/B) GRN WIRE GRY WIRE HILL HOLD SWITCH IG 2 RELAY IMMOBILIZER CONTROL MODULE INHIBITOR SWITCH LEFT DAYTIME RUNNING LIGHT RELAY LEFT FRONT COMBINATION LIGHT (HEADLIGHT BEAM LEVELER) LEFT RADAR SENSOR (MASTER) MAIN FAN RELAY MAIN FAN RELAY 1 MAIN FAN RELAY 2 MAIN FUSE BOX (M/B) MAIN FUSE BOX (M/B) (LEFT SIDE OF ENGINE COMPT) N/A NAVIGATION UNIT OCCUPANT DETECTION CONTROL MODULE PNK WIRE POWER REAR GATE CONTROL MODULE POWER STEERING CONTROL MODULE POWER WINDOW RELAY REAR VEHICLE HEIGHT SENSOR UNIT RED WIRE REVERSE AUTOMATIC BRAKING CONTROL MODULE RIGHT DAYTIME RUNNING LIGHT RELAY RIGHT FRONT COMBINATION LIGHT (HEADLIGHT BEAM LEVELER) RIGHT RADAR SENSOR (SLAVE) SEAT HEATER RELAY FUSE, RELAY BOX (F/B) STEERING ANGLE SENSOR STEERING HEATER RELAY STEERING LOCK CONTROL MODULE STOP LIGHT RELAY SUB FAN RELAY TO IG 1 RELAY (DIAGRAM 4 OF 8) TO MAIN FUSE BOX (M/B) (DIAGRAM 6 OF 8) VDC CONTROL MODULE VIO WIRE W/ NAVIGATION W/ TELEMATICS W/O NAVIGATION WHT WIRE WIPER RELAY YEL WIRE

A/C CONTROL PANEL BLK WIRE BLU WIRE BSD/RCTA OFF SWITCH EPB CONTROL SWITCH FROM MAIN FUSE BOX (M/B) (DIAGRAM 3 OF 8) FUSE, RELAY BOX (F/B) GLOVE BOX ILLUMINATION LIGHT GRN WIRE HAZARD SWITCH HILL HOLD SWITCH ILLUMINATION CONTROL SWITCH LANE DEPARTURE WARNING OFF SWITCH LEFT LICENSE PLATE LIGHT LEFT REAR COMBINATION LIGHT LEFT REAR SEAT HEATER SWITCH LOWER COVER SWITCH (TRUNK LID OPENER) LT BLU WIRE LT GRN WIRE MEMORY HEIGHT SWITCH NCA WIRE OPTION CONNECTOR (FOG LIGHT SWITCH) ORG/ WIRE POCKET LIGHT POWER REAR GATE DRIVER'S SWITCH PRE-COLLISION BRAKE OFF SWITCH REMOTE CONTROL MIRROR SWITCH RIGHT LICENSE PLATE LIGHT RIGHT REAR COMBINATION LIGHT RIGHT REAR SEAT HEATER SWITCH ROLL CONNECTOR SATELLITE SWITCH SEDAN SEDAN WAGON W/O X MODE W/ X MODE SELECT LEVER SPOT MAP LIGHT STEERING COLUMN) STEERING HEATER SWITCH STEERING SWITCH TELEMATICS BUTTON TRAILER CONNECTOR VDC OFF SWITCH VIO WIRE W/ EYESIGHT W/ TELEMATICS W/O EYESIGHT W/O REAR SEAT HEATER W/O TELEMATICS WAGON WHT WIRE X MODE SWITCH YEL WIRE
