Power windows circuit, w/ driver"s & passenger"s seat auto reverse function for Subaru Outback BS (2014-2018)

AUTO DOWN AUTO UP BLK WIRE BLK/PNK WIRE BLK/WHT WIRE BLU WIRE DOOR LOCK SWITCH DOOR LOCKS SYSTEM DOWN FUSE 11 FUSE 16 FUSE 21 FUSE 24 FUSE 29 FUSE 3 FUSE 6 FUSE, RELAY BOX (F/B) GB-1 GRN WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE HOT AT ALL TIMES LEFT FRONT POWER WINDOW MOTOR (MIDDLE OF LEFT FRONT DOOR) LOCK LT BLU WIRE LT GRN WIRE MAIN FUSE BOX (M/B) OFF OFF UP ORG/ WIRE PNK WIRE POWER WINDOW CONTROLLER POWER WINDOW LOCK SWITCH POWER WINDOW MAIN SWITCH POWER WINDOW RELAY RED WIRE RED/BLU WIRE RED/WHT WIRE RELAY ENERGIZED SBF 15 FUSE SWITCH ILLUMINATION LIGHT UNLOCK UP LEFT REAR UP RIGHT REAR VIO WIRE WHT WIRE YEL WIRE

BLK WIRE BLU WIRE DOWN FRONT POWER WINDOW SUB SWITCH GB-1 GRN WIRE GRN/YEL WIRE GRY WIRE LEFT REAR POWER WINDOW MOTOR LEFT REAR POWER WINDOW SWITCH LIGHT OFF ORG/ WIRE PNK WIRE POWER WINDOW CONTROLLER RED WIRE RIGHT FRONT POWER WINDOW MOTOR (MIDDLE OF RIGHT FRONT DOOR) RIGHT REAR POWER WINDOW MOTOR RIGHT REAR POWER WINDOW SWITCH SWITCH ILLUM. VIO WIRE YEL WIRE
