Headlamps leveling circuit, w/o srf for Subaru Outback BS (2014-2018)
Headlamps leveling circuit, w/o srf
AUTO HEADLIGHT BEAM LEVELER CONTROL MODULE
AUTO HEADLIGHT BEAM LEVELER IND
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
COMBINATION METER
COMPUTER
COMPUTER DATA LINES SYSTEM
DRIVE CIRCUIT
FUSE 14
FUSE 15
FUSE 18
FUSE, RELAY BOX (F/B)
GB-3
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRY WIRE
GRY/RED WIRE
HIGH SPEED CAN TRANSCEIVER
LEFT FRONT COMBINATION (HEADLIGHT BEAM LEVER)
MICRO -
ORG/ WIRE
PNK WIRE
POWER
REAR VEHICLE HEIGHT SENSOR
RED WIRE
RIGHT FRONT COMBINATION (HEADLIGHT BEAM LEVER)
SUPPLY CIRCUIT/
VIO WIRE
VIO/YEL WIRE
WHT/RED WIRE
WHT/YEL WIRE
