2.5l, cooling fan circuit for Subaru Outback BS (2014-2018)
2.5l, cooling fan circuit
A/C RELAY HOLDER (LEFT REAR OF ENGINE COMPT)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
COMPUTER DATA LINES SYSTEM
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE SENSOR
FUSE 3
FUSE 31
FUSE 32
FUSE 8
FUSE, RELAY BOX (F/B)
GRN/ORG WIRE
HOT AT ALL TIMES
HOT W/ IG 1 RELAY ENERGIZED
LT GRN WIRE
MAIN FAN MOTOR
MAIN FAN RELAY 1
MAIN FAN RELAY 2
MAIN FUSE BOX (M/B)
PNK WIRE
RED WIRE
RED/WHT WIRE
SUB FAN MOTOR
SUB FAN RELAY
WHT/BLK WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/GRN WIRE
