Car Wiring Diagrams for Immobilizer circuit for Subaru Outback BS (2014-2018)

BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BODY INTEGRATED UNIT BRN WIRE BRN/YEL WIRE CAN TRANSCEIVER CENTER KEYLESS ACCESS INTERIOR ANTENNA COMBINATION METER COMPUTER DATA LINES SYSTEM DOOR LOCKS SYSTEM DRIVE CIRCUIT FRONT KEYLESS ACCESS INTERIOR ANTENNA FUSE 14 FUSE 26 FUSE 3 FUSE 31 FUSE 5 FUSE, RELAY BOX (F/B) FUSE, RELAY BOX (F/B) (LEFT KICK PANEL) GB-1 GB-3 GRN WIRE GRN/BLU WIRE GRN/RED WIRE GRY WIRE HIGH SPEED HOT AT ALL TIMES IMMOBILIZER ANTENNA (W/O PUSH BUTTON START) (CENTER OF DASH) IMMOBILIZER CONTROL MODULE KEY WARNING SWITCH KEYLESS ACCESS CONTROL MODULE (LEFT SIDE OF DASH) MICRO COMPUTER ORG/ WIRE POWER SUPPLY CIRCUIT REAR KEYLESS ACCESS INTERIOR ANTENNA REAR OF LUGGAGE COMPT) RED WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RELAY ENERGIZED SECURITY/ IMMOBILIZER SEDAN STEERING COLUMN) STEERING LOCK CONTROL MODULE VIO/YEL WIRE W/ IMMOBILIZER CONTROL MODULE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE
