Subaru Outback BS (2014-2018) air conditioner control panel Wiring diagram
This page shows the only wiring diagram for the component.air conditioner control panel, which is found in the car Subaru Outback BS (2014-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram air conditioner control panel (1 of 1)
A/C CONTROL MODULE
AIR CONDITIONER CONTROL PANEL
BLK WIRE
BLU WIRE
FUSE 32
FUSE 9
FUSE, RELAY BOX (F/B)
GB-1
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT W/ ACCESSORY RELAY-1 ENERGIZED
LEFT SEAT HEATER LEFT POWER SEAT
LT BLU WIRE
LT GRN WIRE
MAIN FUSE BOX (M/B)
ORG/ WIRE
RED WIRE
RED/GRN WIRE
RELAY HOLDER (RIGHT END OF DASH)
RIGHT SEAT HEATER
RIGHT SEAT HEATER RIGHT POWER SEAT
SBF-2 FUSE
SEAT HEATER RELAY
W/ POWER SEAT
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> Front heated seats circuit -> AIR CONDITIONER CONTROL PANEL
