2.5l, remote starting circuit, w/ push button start for Subaru Outback BR facelift (2012-2014)
2.5l, remote starting circuit, w/ push button start (1 of 2)
AT SELECT LEVER
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BODY INTEGRATED UNIT
BRN/BLK WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
FUSE 12
FUSE 14
FUSE 31
FUSE 4
FUSE 8
FUSE, RELAY BOX (F/B)
GRN WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT W/ ACCESSORY RELAY (PUSH BUTTON START) ENERGIZED
HOT W/ IG 2 RELAY ENERGIZED
HOT W/ IG RELAY 1 (PUSH BUTTON START) ENERGIZED
KEYLESS ACCESS CONTROL MODULE
LT BLU WIRE
P RANGE SWITCH
WHT WIRE
WHT/BLU WIRE
WHT/ORG WIRE
YEL/RED WIRE
2.5l, remote starting circuit, w/ push button start (2 of 2)
2.5L
3.6L
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN/BLK WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
GB-6
GRN/YEL WIRE
HOOD SWITCH
LOCK
LT GRN WIRE
NCA WIRE
PASSENGERS DOOR LOCK SWITCH
POWER WINDOW MAIN SWITCH (DOOR LOCK SWITCH)
REMOTE ENGINE START CONTROL MODULE
STOP LIGHT CONDENSER
STOP LIGHT RESISTOR
STOP LIGHT, BRAKE SWITCH
UNLOCK
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLK WIRE
