2.5l, charging circuit for Subaru Outback BR facelift (2012-2014)
2.5l, charging circuit
BATTERY
BLK/WHT WIRE
BRN WIRE
BRN/WHT WIRE
CHARGE WARNING LIGHT IND
COMBINATION METER
FUSE 2
FUSE 5
FUSE, RELAY BOX (F/B)
FUSE, RELAY BOX (F/B) (LEFT KICK PANEL)
GENERATOR
HOT IN ON OR START
MAIN FUSE BOX (M/B)
MAIN FUSE BOX (M/B) (LEFT SIDE OF ENGINE COMPT)
MAIN SBF FUSE
NCA WIRE
STARTER MOTOR
WHT BRN WIRE
WHT WIRE
WHT/RED WHT WIRE
WHT/RED WIRE
