Subaru Outback BR facelift (2012-2014) yellow ind Wiring diagrams

This page contains all the electrical diagrams for the component. yellow ind, in which he is found in the car Subaru Outback BR facelift (2012-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram yellow ind (1 of 4)

Wiring diagram yellow ind for Subaru Outback BR facelift (2012-2014) (1 of 4)

Get lifetime access to Subaru Outback BR facelift (2012-2014)

ANTENNA BLK WIRE BLU WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM FRONT KEYLESS ACCESS INTERIOR ANTENNA FRONT LOCK BUTTON FUSE FUSE 12 FUSE 5 (F/B) (LEFT KICK PANEL) FUSE 7 FUSE/ RELAY BOX GB-6 (LEFT KICK PANEL) GREEN IND GRN WIRE GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IG REALY 1 ENERGIZED ILL IND LEFT FRONT LOCK BUTTON, KEYLESS ACCESS EXTERIOR ANTENNA LEFT OSCILLATOR LT BLU WIRE LT GRN WIRE LT GRN/WHT WIRE ORG/ WIRE PNK WIRE POWER DISTRIBUTION SYSTEM PUSH BUTTON IGNITION SWITCH RED WIRE RED/WHT WIRE RIGHT FRONT LOCK BUTTON, KEYLESS ACCESS EXTERIOR ANTENNA SENSOR TOUCH STEERING LOCK CONTROL MODULE TOUCH SENSOR VIO WIRE WHT WIRE WHT/BLU WIRE WHT/ORG WIRE YEL WIRE YEL/BLU WIRE YELLOW IND

Go to component -> Forced entry circuit, with keyless access (1 of 4) -> YELLOW IND

Wiring diagram yellow ind (2 of 4)

Wiring diagram yellow ind for Subaru Outback BR facelift (2012-2014) (2 of 4)

Get lifetime access to Subaru Outback BR facelift (2012-2014)

ANTENNA BLK WIRE BLU WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM FRONT KEYLESS ACCESS INTERIOR ANTENNA FRONT LOCK BUTTON FUSE 12 FUSE 32 FUSE 5 FUSE 7 FUSE, RELAY BOX (F/B) GB-6 GREEN IND GRN WIRE GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IG REALY 1 ENERGIZED ILL IND KEYLESS ENTRY CONTROL MODULE LEFT FRONT LOCK BUTTON, KEYLESS ACCESS EXTERIOR ANTENNA LEFT OSCILLATOR LT BLU WIRE LT GRN WIRE LT GRN/WHT WIRE ORG/ WIRE PNK WIRE POWER DISTRIBUTION SYSTEM PUSH BUTTON IGNITION SWITCH RED WIRE RED/WHT WIRE RIGHT FRONT LOCK BUTTON, KEYLESS ACCESS EXTERIOR ANTENNA SECURITY CONTROL MODULE SENSOR STEERING LOCK CONTROL MODULE TOUCH - VIO WIRE WHT WIRE WHT/BLU WIRE WHT/ORG WIRE YEL WIRE YEL/BLU WIRE YELLOW IND

Go to component -> Forced entry circuit, w/ keyless access (1 of 4) -> YELLOW IND
