Subaru Outback BR facelift (2012-2014) shower light Wiring diagrams
This page contains all the electrical diagrams for the component. shower light, in which he is found in the car Subaru Outback BR facelift (2012-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram shower light (1 of 2)
3.6L
A/C CONTROL PANEL
A/C RELAY HOLDER
A/C RELAY HOLDER (LEFT REAR OF ENGINE COMPT)
AIR BAG CONTROL MODULE
AT SELECT LEVER ILLUMINATION LIGHT
AUDIO
AUTOMATIC A/C
BLK WIRE
BLOWER MOTOR RELAY
BLU WIRE
BLU/YEL WIRE
BODY INTEGRATED UNIT
BRN WIRE
CVT A/T
DAYTIME RUNNING RELAY A/C RELAY HOLDER
ENGINE COMPT)
EPB CONTROL MODULE
EPB CONTROL SWITCH
EXCEPT 3.6L
FROM FUSE 12 (DIAGRAM 2 OF 6)
FROM FUSE 7 (DIAGRAM 1 OF 6)
FROM IGNITION SWITCH (DIAGRAM 2 OF 6)
FROM MAIN FUSE BOX (M/B) (DIAGRAM 3 OF 6)
FROM MAIN SBF FUSE (DIAGRAM 1 OF 6)
FRONT FOG LIGHT RELAY
FUSE 10
FUSE 19
FUSE 22
FUSE 25
FUSE 26
FUSE 26 FUSE 19
FUSE 3
FUSE 33
FUSE 34
FUSE 35
FUSE, RELAY BOX (F/B)
FUSE, RELAY BOX (F/B) (LEFT KICK PANEL)
GLOVE BOX ILLUMINATION LIGHT
GRN WIRE
HI HEADLIGHT RELAY
HILL HOLD SWITCH
HORN RELAY
ILLUMINATION A/C CONTROL CONTROL PANEL SWITCH
ILLUMINATION CONTROL SWITCH
INTAKE DOOR ACTUATOR
LEFT FRONT COMBINATION LIGHT (CLEARANCE LIGHT)
LEFT SEAT HEATER SWITCH
LOW HEADLIGHT RELAY
LOWER COVER SWITCH
MAIN FAN RELAY
MAIN FAN RELAY 1
MAIN FAN RELAY 2
MAIN FUSE BOX (M/B)
MAIN FUSE BOX (M/B) (LEFT SIDE OF
MANUAL A/C
NAVIGATION AUDIO UNIT
NAVIGATION UNIT
NCA WIRE
OCCUPANT AIR BAG DETECTION CONTROL CONTROL MODULE MODULE
OCCUPANT DETECTION CONTROL MODULE
ORG/ WIRE
OVERHEAD CONSOLE
OVERHEAD CONSOLE (SHOWER LIGHT)
POWER WINDOW MAIN SWITCH
POWER WINDOW RELAY
PREMIUM BASE
REAR DEFOGGER RELAY
RED WIRE
REMOTE CONTROL MIRROR SWITCH
RIGHT FRONT COMBINATION LIGHT (CLEARANCE LIGHT)
RIGHT SEAT HEATER SWITCH
ROLL CONNECTOR
ROLL CONNECTOR (LEFT SIDE OF DASH)
SATELLITE SWITCH ILLUMINATION LIGHT
SBF-10
SHOWER LIGHT
STEERING ANGLE SENSOR
STEERING SWITCH ILLUMINATION LIGHT
STEREO CAMERA COVER
SUB FAN RELAY
SUB FAN RELAY (EXCEPT 3.6L)
TAIL, ILLUMINATION RELAY
TO AT SELECT LEVER ILLUMINATION LIGHT (DIAGRAM 3 OF 6)
TO FUSE 19 (DIAGRAM 4 OF 6)
TO FUSE 19 (DIAGRAM HI HORN 4 OF 6) HEADLIGHT RELAY RELAY
TO FUSE, RELAY BOX (F/B) (DIAGRAM 1 OF 6)
TO FUSE, RELAY BOX (F/B) (DIAGRAM 6 OF 6)
TO FUSE, RELAY FUSE 3 BOX (F/B) (DIAGRAM 6 OF 6)
VDC CONTROL MODULE
VIO WIRE
W/ NAVIGATION
W/ NAVIGATION W/O NAVIGATION 2.5L 3.6L
W/O NAVIGATION 2.5L 3.6L
WHT WIRE
WIPER RELAY
YEL WIRE
Go to component -> Power distribution circuit (3 of 6) -> SHOWER LIGHT
Wiring diagram shower light (2 of 2)
32 33 COMPUTER DATA LINES SYSTEM
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRAKE OFF
BRAKE OFF IND
BRAKE OFF PRE-COLLISION
BRAKE RELAY
BRN WIRE
BRN/WHT WIRE
CAN TRNSCEIVER, RECEIVER
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DRIVE CIRCUIT
FUSE
FUSE 39
FUSE 4
FUSE 5
FUSE 8
FUSE BLOCK (F/B)
FUSE, RELAY BOX (F/B)
GB-5
GB-5 (RIGHT KICK PANEL)
GB-6 (LEFT KICK PANEL)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN OR OR START
HOT IN OR OR START FUSE, RELAY BOX (F/B) (LEFT KICK PANEL) FUSE 5
J/C
LANE
LANE DEPARTURE
LANE DEPARTURE WARNING OFF
LANE DEPARTURE WARNING OFF IND
MAIN FUSE BOX (M/B)
MAIN FUSE BOX (M/B) (LEFT SIDE OF ENGINE COMPT)
MICRO COMPUTER
NCA WIRE
PRE-COLLISION
PRE-COLLISION BRAKE OFF IND
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RELAY ENERGIZED
RELAY ENERGIZED FUSE FUSE BLOCK (F/B)
SHOWER LIGHT
SPOT MAP LIGHT
STEREO CAMERA
STEREO CAMERA COVER
TFT
TFT (W/ LUMINESCENT METER)
VIO WIRE
WARNING OFF IND
WHT WIRE
WHT/BLU WIRE
YEL/RED WIRE
Go to component -> Stereo camera circuit -> SHOWER LIGHT
