Subaru Outback BR facelift (2012-2014) nca Wiring diagrams
This page contains all the electrical diagrams for the component. nca, in which he is found in the car Subaru Outback BR facelift (2012-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram nca (71 of 91)
A/T
BACK-UP LIGHT RELAY
BACK-UP LIGHT SWITCH
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN/RED WIRE
BRN/YEL WIRE
CVT
EXTERIOR LIGHTS
FUSE 14
FUSE 18
FUSE 4
FUSE, RELAY BOX (F/B) (LEFT KICK PANEL)
GB-9 (LEGACY: CENTER OF REAR PARCEL SHELF) (OUTBACK: LEFT "D" PILLAR)
GRN/BLU WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INHIBITOR SWITCH (TOP OF TRANSMISSION)
M/T
NCA WIRE
REARVIEW CAMERA
REARVIEW MIRROR)
RED WIRE
SYSTEM
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Automatic day/night mirror circuit, with home link & rear camera display -> NCA WIRE
Wiring diagram nca (72 of 91)
A/T
BACKUP LIGHT RELAY (ON SMART MODULE BRACKET)
BACKUP LIGHT SWITCH
BLK WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
BRN/RED WIRE
BRN/YEL WIRE
CVT
FUSE 14
FUSE 18
FUSE 4
FUSE, RELAY BOX (F/B) (LEFT KICK PANEL)
GB-6 (LEFT KICK PANEL)
GRN/BLU WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT W/ IG 2 RELAY ENERGIZED
INHIBITOR SWITCH (TOP OF TRANSMISSION)
J/C
M/T
NCA WIRE
REARVIEW MIRROR)
WHT/BLK WIRE
Go to component -> Automatic day/night mirror circuit, with home link & without rear camera display -> NCA WIRE
Wiring diagram nca (73 of 91)
A/T
BACK-UP LIGHT SWITCH
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BRN WIRE
BRN/RED WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
CVT
FUSE 18
FUSE 6
FUSE, RELAY BOX (F/B) (LEFT KICK PANEL)
GB-5 (RIGHT KICK PANEL)
GRN WIRE
GRN/BLU WIRE
HOT W/ ACCESSORY RELAY ENERGIZED
INHIBITOR SWITCH (TOP OF TRANSMISSION)
M/T
NCA WIRE
REARVIEW MIRROR)
RED WIRE
RELAY ENERGIZED
TCM (LEFT SIDE OF DASH)
WHT/BLK WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Automatic day/night mirror circuit, without home link -> NCA WIRE
Wiring diagram nca (74 of 91)
& RECEIVER
3 9 LOCK DOOR LOCK SWITCH
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/BLK WIRE
BRN/RED WIRE
BRN/WHT WIRE
CIRCUIT
CIRCUIT DRIVE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DOOR WARNING LIGHT IND
FUSE
GB-11 (RIGHT TOP OF REAR GATE)
GB-6 (LEFT KICK PANEL)
GB-7 (SEDAN: CENTER FRONT OF LUGGAGE COMPT) (WAGON: RIGHT QUARTERPANEL)
GB-8 (BASE OF RIGHT "B" PILLAR)
GRN WIRE
HOOD SWITCH (RIGHT SIDE OF ENGINE COMPT)
HORN (FRONT CENTER OF ENGINE COMPT)
HOT W/ HORN RELAY ENERGIZED MAIN FUSE BOX (M/B) (LEFT SIDE OF FUSE ENGINE COMPT)
LCD EACH DOOR SECURITY/ OPEN/ IMMOBILIZER CLOSE LIGHT IND DISPLAY
LOCK
LOWER COVER SWITCH (TRUNK LID OPENER)
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/YEL WIRE
MICRO COMPUTER
NCA WIRE
PASSENGERS DOOR LOCK SWITCH
POWER SUPPLY
POWER WINDOW MAIN SWITCH
REAR GATE LOCK ACTUATOR, LATCH SWITCH (BOTTOM CENTER OF REAR GATE)
REAR GATE OPENER BUTTON
RED WIRE
RED/GRN WIRE
REMOTE ENGINE START CONTROL MODULE (LEFT SIDE OF DASH)
RIGHT FRONT DOOR LOCK ACTUATOR (IN RIGHT FRONT DOOR)
RIGHT REAR DOOR LOCK ACTUATOR (IN RIGHT REAR DOOR)
SEDAN
TRANSCEIVER/
TRUNK LID LOCK ACTUATOR, SWITCH (REAR CENTER OF LUGGAGE COMPT)
TRUNK OPENER CANCEL SWITCH
UNLOCK
WAGON
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Forced entry circuit, without keyless access (2 of 2) -> NCA WIRE
Wiring diagram nca (75 of 91)
BLK WIRE
BLK/BLU WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BODY INTEGRATED UNIT (CENTER OF DASH)
BRN/BLK WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
GB-5 (RIGHT KICK PANEL)
GB-6 (LEFT KICK PANEL)
GB-8 (BASE OF RIGHT "B" PILLAR)
GRN WIRE
GRN/WHT WIRE
HORNS SYSTEM
LEFT FRONT DOOR LOCK ACTUATOR (IN DRIVER'S DOOR)
LEFT REAR DOOR LOCK ACTUATOR (IN LEFT REAR DOOR)
LEFT STATUS SWITCH
LOCK
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/YEL WIRE
NCA WIRE
PASSENGERS DOOR LOCK SWITCH
POWER WINDOW MAIN SWITCH (DOOR LOCK SWITCH)
REAR GATE LOCK ACTUATOR, LATCH SWITCH (BOTTOM CENTER OF REAR GATE)
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT FRONT DOOR LOCK ACTUATOR (IN RIGHT FRONT DOOR)
RIGHT REAR DOOR LOCK ACTUATOR (IN RIGHT REAR DOOR)
RIGHT STATUS SWITCH
UNLOCK
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> Power door locks circuit, with keyless access (4 of 4) -> NCA WIRE
Wiring diagram nca (76 of 91)
& RECEIVER
3 9 LOCK DOOR LOCK SWITCH
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/BLK WIRE
BRN/RED WIRE
BRN/WHT WIRE
CIRCUIT
CIRCUIT DRIVE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DOOR WARNING LIGHT IND
FUSE
GB-11 (RIGHT TOP OF REAR GATE)
GB-6 (LEFT KICK PANEL)
GB-7 (SEDAN: CENTER FRONT OF LUGGAGE COMPT) (WAGON: RIGHT QUARTERPANEL)
GB-8 (BASE OF RIGHT "B" PILLAR)
GRN WIRE
HOOD SWITCH (RIGHT SIDE OF ENGINE COMPT)
HORN (FRONT CENTER OF ENGINE COMPT)
HOT W/ HORN RELAY ENERGIZED MAIN FUSE BOX (M/B) (LEFT SIDE OF FUSE ENGINE COMPT)
LCD EACH DOOR SECURITY/ OPEN/ IMMOBILIZER CLOSE LIGHT IND DISPLAY
LOCK
LOWER COVER SWITCH (TRUNK LID OPENER)
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/YEL WIRE
MICRO COMPUTER
NCA WIRE
PASSENGERS DOOR LOCK SWITCH
POWER SUPPLY
POWER WINDOW MAIN SWITCH
REAR GATE LOCK ACTUATOR, LATCH SWITCH (BOTTOM CENTER OF REAR GATE)
REAR GATE OPENER BUTTON
RED WIRE
RED/GRN WIRE
REMOTE ENGINE START CONTROL MODULE (LEFT SIDE OF DASH)
RIGHT FRONT DOOR LOCK ACTUATOR (IN RIGHT FRONT DOOR)
RIGHT REAR DOOR LOCK ACTUATOR (IN RIGHT REAR DOOR)
SEDAN
TRANSCEIVER/
TRUNK LID LOCK ACTUATOR, SWITCH (REAR CENTER OF LUGGAGE COMPT)
TRUNK OPENER CANCEL SWITCH
UNLOCK
WAGON
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Power door locks circuit, without keyless access (2 of 2) -> NCA WIRE
Wiring diagram nca (77 of 91)
BLK WIRE
BLU WIRE
CHANGE OVER SWITCH
DEFOGGER SYSTEM
FUSE 6
FUSE, RELAY BOX (F/B) (LEFT KICK PANEL)
GB-6 (LEFT KICK PANEL)
GRN WIRE
GRY WIRE
HOT W/ ACCESSORY RELAY ENERGIZED
LEFT OUTER MIRROR ASSEMBLY
LEFT/ UP/ RIGHT DOWN MOTOR MOTOR
MIRROR HEATER
MIRROR RETRACTABLE HEATER MIRROR MOTOR
NCA WIRE
RED WIRE
REMOTE CONTROL MIRROR SWITCH
REMOTE CONTROL SWITCH
RETRACTION SWITCH
RIGHT/ RETRACTABLE LEFT MIRROR MOTOR MOTOR RIGHT OUTER MIRROR ASSEMBLY
TURN LIGHT
UP/ DOWN MOTOR
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power mirror circuit, with retractable outer mirror -> NCA WIRE
Wiring diagram nca (78 of 91)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN/YEL WIRE
FUSE
FUSE BOX (M/B) (LEFT SIDE OF ENGINE COMPT)
FUSE, RELAY BOX (F/B) (LEFT KICK PANEL)
GB-9 (LEFT "D" PILLAR)
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT W/ IG 2 RELAY ENERGIZED
MAIN FUSE
NCA WIRE
REARVIEW MIRROR (W/ REARVIEW DISPLAY)
RED WIRE
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Rear view camera circuit, base without navigation -> NCA WIRE
Wiring diagram nca (79 of 91)
AUDIO
BLK WIRE
BLK/YEL WIRE
BLU/ORG WIRE
BLU/YEL WIRE
BRN/YEL WIRE
FUSE
GB-9 (WAGON) (LEFT "D" PILLAR) GB-7 (SEDAN) (CENTER FRONT OF LUGGAGE COMPT)
GRN/WHT WIRE
HOT AT ALL TIMES
MAIN FUSE BOX (M/B) (LEFT SIDE OF ENGINE COMPT)
NCA WIRE
REARVIEW CAMERA (SEDAN: LEFT REAR OF LUGGAGE COMPT) (WAGON: IN REAR GATE)
RED WIRE
SEDAN
SEDAN WAGON
WAGON
WAGON SEDAN
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Rear view camera circuit, premium without navigation -> NCA WIRE
Wiring diagram nca (80 of 91)
BLK WIRE
BLK/YEL WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN/YEL WIRE
FUSE
FUSE, RELAY BOX (F/B) (LEFT KICK PANEL)
GB-9 (WAGON) (LEFT "D" PILLAR) GB-7 (SEDAN) (CENTER FRONT OF LUGGAGE COMPT)
GRN/WHT WIRE
HOT AT ALL TIMES
MAIN FUSE BOX (M/B) (LEFT SIDE OF ENGINE COMPT)
NAVIGATION UNIT
NCA WIRE
REARVIEW CAMERA (SEDAN: LEFT REAR OF LUGGAGE COMPT) (WAGON: IN REAR GATE)
RED WIRE
SEDAN
SEDAN WAGON
WAGON
WAGON SEDAN
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Rear view camera circuit, with navigation -> NCA WIRE
