Subaru Outback BR facelift (2012-2014) lighting switch combination switch Wiring diagram
This page shows the only wiring diagram for the component.lighting switch combination switch, which is found in the car Subaru Outback BR facelift (2012-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lighting switch combination switch (1 of 1)
2.5L
2.5L 3.6L
3.6L
AUTO
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/ORG WIRE
BLU/YEL WIRE
BODY INTEGRATED UNIT
BODY INTEGRATED UNIT (CENTER OF DASH)
BRAKE RELAY
BRN WIRE
BRN/WHT WIRE
COMBINATION SWITCH
COMPUTER DATA LINES SYSTEM
ECM (RIGHT SIDE
GB-7
GB-7 (CENTER FRONT OF LUGGAGE COMPT)
GB-7 (RIGHT QUARTERPANEL)
GB-8
GB-8 (BASE OF RIGHT "B" PILLAR)
GB-9
GB-9 (CENTER OF REAR PARCEL SHELF)
GB-9 (LEFT "D" PILLAR)
GRN RED/ WIRE
GRN WIRE
HEADLIGHTS SYSTEM
HIGH MOUNTED STOP LIGHT
LEFT LICENSE PLATE LIGHT
LEFT REAR COMBI- NATION LIGHT
LEFT REAR COMBINATION LIGHT
LEFT REAR FINISHER LIGHT (TAIL LIGHT)
LICENSE PLATE LIGHT
LIGHTING SWITCH
LIGHTING SWITCH COMBINATION SWITCH
MAIN FUSE BOX (M/B)
MAIN FUSE BOX (M/B) BRAKE (LEFT SIDE OF RELAY ENGINE COMPT)
NCA WIRE
OF DASH)
OFF
RED WIRE
RED/GRN WIRE
RIGHT LICENSE PLATE LIGHT
RIGHT REAR COMBI- NATION LIGHT
RIGHT REAR COMBINATION LIGHT
RIGHT REAR FINISHER LIGHT (TAIL LIGHT)
SEDAN
STOP
TAIL
TCM (CVT) (LEFT SIDE OF DASH)
TRAILER CONNECTOR
TRAILER CONNECTOR (WAGON)
TURN
VDC CONTROL MODULE
VDC CONTROL MODULE (RIGHT REAR CORNER OF ENGINE COMPT)
VIO/WHT WIRE
W/ EYESIGHT
W/ REAR SPOILER
W/O EYESIGHT
WAGON
WHT WIRE
YEL BLK/ WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> LIGHTING SWITCH COMBINATION SWITCH
