Subaru Outback BR facelift (2012-2014) blk/blu Wiring diagrams
This page contains all the electrical diagrams for the component. blk/blu, in which he is found in the car Subaru Outback BR facelift (2012-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram blk/blu (31 of 40)
A/C CONTROL MODULE
A/C CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
AIR MIX DOOR ACTUATOR
AIR MIX DOOR ACTUATOR (CENTER OF DASH)
AIR MIX DOOR ACTUATOR (PASSENGER'S SEAT)
AIR MIX DOOR ACTUATOR (PASSENGER'S SEAT) (RIGHT SIDE OF DASH)
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLOWER MOTOR
BLU WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/WHT WIRE
COMPRESSOR SOLENOID
COMPUTER DATA LINES SYSTEM
EVAPORATOR SENSOR
EVAPORATOR SENSOR (LEFT SIDE OF DASH)
FLOW SENSOR
FLOW SENSOR (LEFT SIDE OF ENGINE COMPT)
FUSE 12
FUSE 12 (F/B) (LEFT KICK PANEL)
FUSE 4
FUSE 5
FUSE 7
FUSE, RELAY BOX (F/B)
FUSE/ RELAY BOX
GB-5
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES MAIN FUSE BOX (M/B) FUSE 5 (LEFT SIDE OF ENGINE COMPT)
HOT IN ON OR START
IN-VEHICLE SENSOR
IN-VEHICLE SENSOR (BEHIND CENTER CONSOLE)
INTAKE DOOR ACTUATOR
LIGHT CONTROL SENSOR
LIGHT CONTROL SENSOR (BASE OF RIGHT "A" PILLAR)
LT BLU WIRE
LT GRN/WHT WIRE
MAIN FUSE BOX (M/B)
MODE DOOR ACTUATOR
MODE DOOR ACTUATOR (RIGHT SIDE OF DASH)
ORG/ WIRE
ORG/BLU WIRE
PNK/GRN WIRE
PRESSURE SENSOR
PRESSURE SENSOR (TOP REAR OF ENGINE)
RED WIRE
RED/BLK WIRE
VIO/WHT WIRE
VIO/YEL WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> 2.5l, automatic a/c circuit (1 of 3) -> BLK/BLU WIRE
Wiring diagram blk/blu (32 of 40)
BATTERY
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLK/YEL WIRE
CLUTCH STROKE SENSOR (CLUTCH START SWITCH) (LEFT SIDE OF DASH)
CVT
CVT M/T
ECM (RIGHT SIDE OF DASH)
FUSE 21
FUSE, RELAY BOX (F/B) (LEFT KICK PANEL)
GRN/BLK WIRE
IGNITION SWITCH
INHIBITOR SWITCH (TOP OF TRANSMISSION)
M/T
MAIN FUSE BOX (M/B) MAIN SBF FUSE (LEFT SIDE OF ENGINE COMPT)
NCA WIRE
NEUTRAL POSITION SWITCH
OFF ON
SBF-5 FUSE
STARTER MOTOR
STARTER RELAY FUSE, RELAY BOX (F/B)
WHT WIRE
WHT/BLK (OR WHT) WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
Go to component -> 2.5l, starting circuit, without push button start -> BLK/BLU WIRE
Wiring diagram blk/blu (33 of 40)
BATTERY
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLK/YEL WIRE
CLUTCH STROKE SENSOR (CLUTCH START SWITCH)
CVT
FUSE 21
FUSE, RELAY BOX (F/B)
GRN/BLK WIRE
IGNITION SWITCH
INHIBITOR SWITCH (TOP OF TRANSMISSION)
M/T
MAIN FUSE BOX (M/B)
MAIN SBF FUSE
NCA WIRE
NEUTRAL POSITION SWITCH
OFF
SBF-5 FUSE
STARTER MOTOR
STARTER RELAY
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
Go to component -> 2.5l, starting circuit, w/o push button start -> BLK/BLU WIRE
Wiring diagram blk/blu (34 of 40)
A/C CONTROL MODULE
A/C CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
AIR MIX DOOR ACTUATOR (DRIVER'S SEAT)
AIR MIX DOOR ACTUATOR (PASSENGER'S SEAT)
AIR MIX DOOR ACTUATOR (PASSENGER'S SEAT) (RIGHT SIDE OF DASH)
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLOWER MOTOR
BLU WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/WHT WIRE
COMPRESSOR SOLENOID
COMPUTER DATA LINES SYSTEM
EVAPORATOR SENSOR
EVAPORATOR SENSOR (LEFT SIDE OF DASH)
FLOW SENSOR
FLOW SENSOR (LEFT SIDE OF ENGINE COMPT)
FUSE 12
FUSE 12 (F/B) (LEFT KICK PANEL)
FUSE 22
FUSE 4
FUSE 5
FUSE 7
FUSE, RELAY BOX (F/B)
FUSE/ RELAY BOX
GB-5
GB-5 (RIGHT KICK PANEL)
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES MAIN FUSE BOX (M/B) FUSE 5 (LEFT SIDE OF ENGINE COMPT)
HOT IN ON OR START
IN-VEHICLE SENSOR
IN-VEHICLE SENSOR (BEHIND CENTER CONSOLE)
INTAKE DOOR ACTUATOR
LIGHT CONTROL SENSOR
LIGHT CONTROL SENSOR (BASE OF RIGHT "A" PILLAR)
LT BLU WIRE
LT GRN/WHT WIRE
MAIN FUSE BOX (M/B)
MODE DOOR ACTUATOR
MODE DOOR ACTUATOR (RIGHT SIDE OF DASH)
ORG/ WIRE
ORG/BLU WIRE
PNK/GRN WIRE
PRESSURE SENSOR
PRESSURE SENSOR (TOP REAR OF ENGINE)
RED WIRE
RED/BLK WIRE
VIO/WHT WIRE
VIO/YEL WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> 3.6l, automatic a/c circuit (1 of 2) -> BLK/BLU WIRE
Wiring diagram blk/blu (35 of 40)
BATTERY
BLK/BLU WIRE
ECM (RIGHT SIDE OF DASH)
FUSE, RELAY BOX (F/B) FUSE (LEFT KICK PANEL)
GRN/BLK WIRE
IGNITION SWITCH
INHIBITOR RELAY (ON SMART MODULE BRACKET)
MAIN FUSE BOX (M/B) MAIN SBF FUSE (LEFT SIDE OF SBF-5 FUSE ENGINE COMPT)
NCA WIRE
OFF ON
STARTER MOTOR
STARTER RELAY FUSE, RELAY BOX (F/B)
TCM (LEFT SIDE OF DASH)
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/ORG WIRE
Go to component -> 3.6l, starting circuit, without push button start -> BLK/BLU WIRE
Wiring diagram blk/blu (36 of 40)
BATTERY
BLK WIRE
BLK/BLU WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
ECM (RIGHT SIDE OF DASH)
FUSE 21
FUSE, RELAY BOX (F/B) (LEFT KICK PANEL)
GB-6 (LEFT KICK PANEL)
GRN/BLK WIRE
IGNITION SWITCH
INHIBITOR RELAY
KEYLESS ACCESS CONTROL MODULE (CENTER FRONT OF LUGGAGE COMPT)
LT BLU WIRE
MAIN FUSE BOX (M/B) MAIN SBF FUSE (LEFT SIDE OF ENGINE COMPT)
NCA WIRE
OFF ON
PUSH BUTTON IGNITION SWITCH
RED WIRE
SBF-5 FUSE
STARTER MOTOR
STARTER RELAY RELAY HOLDER (RIGHT END OF DASH)
TCM (LEFT SIDE OF DASH)
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/ORG WIRE
Go to component -> 3.6l, starting circuit, with push button start -> BLK/BLU WIRE
Wiring diagram blk/blu (37 of 40)
Go to component -> 3.6l, starting circuit, w/o push button start -> BLK/BLU WIRE
Wiring diagram blk/blu (38 of 40)
BATTERY
BLK WIRE
BLK/BLU WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
FUSE 21
FUSE, RELAY BOX (F/B)
GB-6
GRN/BLK WIRE
IGNITION SWITCH
INHIBITOR RELAY
KEYLESS ACCESS CONTROL MODULE
LT BLU WIRE
MAIN FUSE BOX (M/B)
MAIN SBF FUSE
NCA WIRE
OFF
PUSH BUTTON IGNITION SWITCH
RED WIRE
RELAY HOLDER (RIGHT END OF DASH)
SBF-5 FUSE
STARTER MOTOR
STARTER RELAY
TCM
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/ORG WIRE
Go to component -> 3.6l, starting circuit, w/ push button start -> BLK/BLU WIRE
Wiring diagram blk/blu (39 of 40)
BLK WIRE
BLK/BLU WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BODY INTEGRATED UNIT (CENTER OF DASH)
BRN/BLK WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
GB-5 (RIGHT KICK PANEL)
GB-6 (LEFT KICK PANEL)
GB-8 (BASE OF RIGHT "B" PILLAR)
GRN WIRE
GRN/WHT WIRE
HORNS SYSTEM
LEFT FRONT DOOR LOCK ACTUATOR (IN DRIVER'S DOOR)
LEFT REAR DOOR LOCK ACTUATOR (IN LEFT REAR DOOR)
LEFT STATUS SWITCH
LOCK
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/YEL WIRE
NCA WIRE
PASSENGERS DOOR LOCK SWITCH
POWER WINDOW MAIN SWITCH (DOOR LOCK SWITCH)
REAR GATE LOCK ACTUATOR, LATCH SWITCH (BOTTOM CENTER OF REAR GATE)
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT FRONT DOOR LOCK ACTUATOR (IN RIGHT FRONT DOOR)
RIGHT REAR DOOR LOCK ACTUATOR (IN RIGHT REAR DOOR)
RIGHT STATUS SWITCH
UNLOCK
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> Forced entry circuit, with keyless access (4 of 4) -> BLK/BLU WIRE
Wiring diagram blk/blu (40 of 40)
BLK WIRE
BLK/BLU WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BODY INTEGRATED UNIT (CENTER OF DASH)
BRN/BLK WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
GB-5 (RIGHT KICK PANEL)
GB-6 (LEFT KICK PANEL)
GB-8 (BASE OF RIGHT "B" PILLAR)
GRN WIRE
GRN/WHT WIRE
HORNS SYSTEM
LEFT FRONT DOOR LOCK ACTUATOR (IN DRIVER'S DOOR)
LEFT REAR DOOR LOCK ACTUATOR (IN LEFT REAR DOOR)
LEFT STATUS SWITCH
LOCK
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/YEL WIRE
NCA WIRE
PASSENGERS DOOR LOCK SWITCH
POWER WINDOW MAIN SWITCH (DOOR LOCK SWITCH)
REAR GATE LOCK ACTUATOR, LATCH SWITCH (BOTTOM CENTER OF REAR GATE)
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT FRONT DOOR LOCK ACTUATOR (IN RIGHT FRONT DOOR)
RIGHT REAR DOOR LOCK ACTUATOR (IN RIGHT REAR DOOR)
RIGHT STATUS SWITCH
UNLOCK
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> Power door locks circuit, with keyless access (4 of 4) -> BLK/BLU WIRE
