Subaru Outback BR facelift (2012-2014) back-up light relay Wiring diagrams
This page contains all the electrical diagrams for the component. back-up light relay, in which he is found in the car Subaru Outback BR facelift (2012-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram back-up light relay (1 of 3)
Go to component -> Automatic day/night mirror circuit, w/ home link & rear camera display -> BACK-UP LIGHT RELAY
Wiring diagram back-up light relay (2 of 3)
Go to component -> Automatic day/night mirror circuit, with home link & rear camera display -> BACK-UP LIGHT RELAY
Wiring diagram back-up light relay (3 of 3)
Go to component -> Automatic day/night mirror circuit, w/o home link -> BACK-UP LIGHT RELAY
