Center differential lock circuit for Subaru Outback BR (2009-2012)

AUTO IND AUTO IND LIGHT AUTO MANUAL BLK WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/WHT WIRE BLU/YEL WIRE BRN/WHT WIRE CAN TRANSCEIVER, RECEIVER CENTER DIFFERENTIAL CIRCUIT REVERSE COMBINATION METER COMPUTER DATA LINES SYSTEM DCCD CM DCCD RELAY DRIVE CIRCUIT ENGINE COOLANT TEMPERATURE GAUGE FUSE 12 FUSE 5 FUSE 7 GB-11 (UNDER CENTER CONSOLE) GB-3 (RIGHT END OF DASH) GB-4 (CENTER OF DASH) GB-7 (NEAR RIGHT "C" PILLAR) GB-9 (BASE OF LEFT "C" PILLAR) GRN WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/RED WIRE HOT AT ALL TIMES FUSE, RELAY BOX (F/B) HOT AT ALL TIMES MAIN FUSE BOX (M/B) FUSE 12 (LEFT REAR OF ENGINE COMPT) HOT IN ON OR START J/C LCD TORQUE INDICATOR LIGHT LT GRN/RED WIRE MICRO COMPUTER MULTI SELECT SWITCH (DCCD) NCA WIRE OIL PRESSURE SWITCH (FRONT OF ENGINE) OIL PRESSURE WARNING LIGHT IND PNK WIRE POWER SUPPLY CIRCUIT REAR DIFFERENTIAL OIL TEMPERATURE SWITCH REAR DIFFERENTIAL OIL TEMPERATURE WARNING LIGHT IND RED WIRE RED/WHT WIRE SHIFT TACHO- SPEEDO- METER METER UP IND VIO/RED WIRE WHT WIRE WHT/BLU WIRE YEL/RED WIRE
