Subaru Outback BR (2009-2012) yaw rate vdc steering control angle g sensor module sensor Wiring diagram
This page shows the only wiring diagram for the component.yaw rate vdc steering control angle g sensor module sensor, which is found in the car Subaru Outback BR (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram yaw rate vdc steering control angle g sensor module sensor (1 of 1)
A/C CONTROL PANEL (AUTOMATIC A/C)
A/T
ACCESSORY RELAY
AIR BAG CONTROL MODULE
AIR MIX MODE DOOR DOOR ACTUATOR ACTUATOR
AUTOMATIC A/C
BACKUP LIGHT SWITCH BODY INTEGRATED UNIT
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BODY INTEGRATED UNIT
BRN/WHT WIRE
COMBINATION METER
COMBINATION SWITCH
FROM MAIN FUSE BOX (M/B) (DIAGRAM 1 OF 4)
FRONT ACCESSORY POWER SUPPLY SOCKET
FRONT WASHER MOTOR
FUSE 11 FUSE 5
FUSE 13
FUSE 18
FUSE 20
FUSE 23
FUSE 24
FUSE 25
FUSE 30
FUSE 31
FUSE 33
FUSE 6
FUSE 7
FUSE, RELAY BOX (F/B)
GB-12 (HO TURBO: UNDER CENTER OF DASH)
GB-5 (CENTER OF DASH)
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/YEL WIRE
GRY/RED WIRE
IGNITION SWITCH
INHIBITOR SWITCH
LEFT FUSE, RELAY BOX (F/B) (LEFT SIDE OF DASH)
LEFT FUSE, RELAY BOX (F/B) GB-7 (LEFT SIDE) (NEAR OF DASH) RIGHT "C" PILLAR)
M/T
NAVIGATION AUDIO FRONT UNIT WIPER MOTOR
NCA WIRE
OFF
OFF ON
REAR ACCESSORY POWER SUPPLY SOCKET
REAR REAR WASHER WIPER MOTOR MOTOR (WAGON)
RED WIRE
RELAY
REMOTE REARVIEW CONTROL MIRROR MIRROR SWITCH
SEAT HEATER RELAY
TO CLUTCH SWITCH
TO FUSE 26 (DIAGRAM 4 OF 4)
TO FUSE 4 (DIAGRAM 4 OF 4)
TO FUSE, RELAY BOX (F/B)
TPM IMPACT SENSOR CONTROL MODULE
W/ W/O NAVIGATION NAVIGATION
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
YAW RATE VDC STEERING CONTROL ANGLE G SENSOR MODULE SENSOR
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Power distribution circuit (3 of 4) -> YAW RATE VDC STEERING CONTROL ANGLE G SENSOR MODULE SENSOR
