Subaru Outback BR (2009-2012) int off on Wiring diagram
This page shows the only wiring diagram for the component.int off on, which is found in the car Subaru Outback BR (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram int off on (1 of 1)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
BODY INTEGRATED UNIT (CENTER OF DASH)
BRN WIRE
BRN/WHT WIRE
COMBINATION METER
COMBINATION SWITCH
DRIVE CIRCUIT
FLUID RESERVOIR)
FUSE
FUSE 27
FUSE, RELAY BOX (F/B) (LEFT KICK PANEL)
GB-5 (RIGHT KICK PANEL)
GB-8 (BASE OF RIGHT "B" PILLAR)
GRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INT OFF ON
INT ON OFF ON+WASH WASH
LOW-WASHER FLUID WARNING LIGHT INDICATOR
LT GRN WIRE
MAIN FUSE BLOCK (M/B)
MAIN SBF FUSE
MICRO COMPUTER
NCA WIRE
ON+WASH
ORG/ WIRE
REAR WASHER MOTOR (LEFT FRONT OF ENGINE COMPT)
REAR WIPER MOTOR (IN REAR GATE)
REAR WIPER/ WASHER SWITCH
RED WIRE
WASH
WASHER LEVEL SENSOR (IN WASHER
WHT WIRE
WHT/BLU WIRE
WIPER RELAY
Go to component -> Rear wiper/washer circuit -> INT OFF ON
