Subaru Outback BR (2009-2012) fuse fb Wiring diagram
This page shows the only wiring diagram for the component.fuse fb, which is found in the car Subaru Outback BR (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse fb (1 of 1)
ANTENNA AMPLIFIER (SEDAN: LEFT "C" PILLAR) (WAGON: LEFT REAR QUARTERPANEL)
AUX INPUT TERMINAL
BLK WIRE
BLK/BLU WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/ORG WIRE
BLU/RED WIRE
BRN WIRE
BRN/YEL WIRE
EXTERIOR LIGHTS SYSTEM COMPUTER DATA LINES SYSTEM
FUSE
FUSE 8
FUSE FB
FUSE/ RELAY BOX
GB-11 (HO TURBO: UNDER CENTER CONSOLE)
GRN WIRE
GRN/YEL WIRE
GRY WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC
INSTRUMENT CLUSTER SYSTEM COMPUTER DATA LINES SYSTEM
LEFT FRONT DOOR SPEAKER
LEFT FRONT DOOR TWEETER
LEFT REAR DOOR SPEAKER
LT BLU WIRE
LT GRN/RED WIRE
MAIN FUSE BOX (M/B) (LEFT REAR OF ENGINE COMPT)
MODE
MUTE
NAVIGATION UNIT
NCA WIRE
PARKING BRAKE SWITCH (BASE OF PARK BRAKE LEVER)
PNK WIRE
PNK/GRN WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RELAY ENERGIZED
RIGHT FRONT DOOR SPEAKER
RIGHT FRONT DOOR TWEETER
RIGHT REAR DOOR SPEAKER
ROLL CONNECTOR
SATELLITE SWITCH
SEEK DOWN
SEEK UP
STOP MAP LIGHT (HANDS-FREE MICROPHONE)
VIO WIRE
VIO/RED WIRE
VOL (-)
W/O SUNROOF W/ SUNROOF
WHT/BLK WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Navigation circuit -> FUSE FB
