Car Wiring Diagrams for Forced entry circuit for Subaru Outback BP facelift (2006-2009)

AUTOMATIC A/C BLK WIRE BLU WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/RED WIRE COMBINATION METER COMPUTER DATA LINES SYSTEM DOOR IND LIGHT SECURITY IND LIGHT FUSE 18 FUSE 2 (ON LEFT SIDE OF ENGINE COMPT) FUSE, RELAY BOX (F/B) (BEHIND LEFT SIDE OF DASH) GB-4 (BEHIND RIGHT SIDE OF DASH) GB-5 (BEHIND CENTER OF DASH) GB-7 (UNDER RIGHT FRONT SEAT) GB-8 (WAGON: UNDER RIGHT TAILLIGHT ASSEMBLY) (SEDAN: NEAR LICENSE PLATE LIGHT) GRN WIRE GRN/BLK WIRE HORNS SYSTEM HOT AT ALL TIMES HOT IN ON OR START IGNITION SWITCH IMMOBILIZER CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) IMPACT SENSOR (BEHIND CENTER OF DASH) KEYLESS ENTRY CONTROL MODULE (BEHIND LEFT END OF DASH) LEFT FRONT DOOR SWITCH (AT REAR OF LEFT FRONT DOOR) LEFT REAR DOOR SWITCH (AT REAR OF LEFT REAR DOOR) LOCK LT GRN/BLK WIRE MAIN FUSE BOX (M/B) MANUAL A/C RED WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT DOOR SWITCH (AT REAR OF RIGHT FRONT DOOR) RIGHT REAR DOOR SWITCH (FORWARD OF RIGHT REAR WHEELWELL) SECURITY HORN (AT RIGHT REAR CORNER OF ENGINE COMPT) SECURITY HORN RELAY (BEHIND LEFT SIDE OF DASH) STARTER CUT RELAY (UNDER RIGHT FRONT OF CENTER CONSOLE) STARTING/ CHARGING SYSTEM WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/RED WIRE
