Subaru Outback BP facelift (2006-2009) ground joint Wiring diagram
This page shows the only wiring diagram for the component.ground joint, which is found in the car Subaru Outback BP facelift (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ground joint (1 of 1)
7 8 16 4 5 DATA LINK CONNECTOR (BEHIND DASH, LEFT OF STEERING COLUMN)
ABS "G" SENSOR (UNDER REAR OF CENTER CONSOLE)
ABS CONTROL MODULE (ON RIGHT SIDE OF ENGINE COMPT)
ABS WARNING LIGHT IND
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/YEL WIRE
CAN JOINT
CIRCUIT REVERSE
COMBINATION METER
DRIVER`S CONTROL CENTER DIFFERENTIAL CONTROL MODULE (2.5L TURBO) (BEHIND CENTER
ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
EXCEPT 2.5L TURBO
FUSE
FUSE 13
FUSE 16
FUSE 18
FUSE 8
FUSE, RELAY BOX (F/B) (BEHIND LEFT SIDE
GB-3
GB-4 (BEHIND RIGHT SIDE OF DASH)
GRN WIRE
GRN/BLK WIRE
GROUND JOINT
HOT AT ALL TIMES
HOT IN ON OR START
LEFT FRONT ABS SENSOR (BEHIND LEFT FRONT WHEEL HUB/SPINDLE ASSEMBLY)
LEFT REAR ABS SENSOR (BEHIND LEFT REAR WHEEL HUB/SPINDLE ASSEMBLY)
LT BLU WIRE
LT GRN/BLK WIRE
LT GRN/YEL WIRE
MAIN FUSE BOX (ON LEFT SIDE OF ENGINE COMPT)
MOTOR RELAY
NCA WIRE
OF DASH)
PARKING BRAKE WARNING LIGHT IND (EXCEPT 2.5L TURBO)
PUMP MOTOR
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
REVERSE CIRCUIT
RIGHT FRONT ABS SENSOR (BEHIND RIGHT FRONT WHEEL HUB/SPINDLE ASSEMBLY)
RIGHT REAR ABS SENSOR (BEHIND RIGHT REAR WHEEL HUB/SPINDLE ASSEMBLY)
RR OUT RR IN RL OUT RL IN FR OUT FR IN FL OUT FL IN SOLENOID VALVE
SBF HOLDER (ON LEFT SIDE OF ENGINE COMPT)
SBF-5 FUSE
TRANSMISSION CONTROL MODULE (EXCEPT 2.5L TURBO)
VALVE RELAY
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
Go to component -> Anti-lock brakes circuit -> GROUND JOINT
