Car Wiring Diagrams for Heated seats circuit for Subaru Outback BP (2003-2006)

BLK WIRE BLK/WHT WIRE BLU WIRE BLU/WHT WIRE FUSE FUSE 4 FUSE/ RELAY BOX (LEFT END OF DASH) GB-3 (AT REAR OF ENGINE COMPARTMENT) GB-9 (SEDAN: AT TOP CENTER OF TRUNK) HIGH OFF LOW HOT AT ALL TIMES MAIN FUSE BOX (AT LEFT SIDE OF ENGINE COMPT) SBF-2 FUSE HOT IN ACC OR ON LEFT SEAT HEATER (UNDER LEFT FRONT SEAT) LEFT SEAT HEATER SWITCH LT GRN WIRE RED WIRE RED/BLU WIRE RED/WHT WIRE RELAY BLOCK (RIGHT SIDE OF ENGINE COMPT) RIGHT SEAT HEATER (UNDER RIGHT FRONT SEAT) RIGHT SEAT HEATER SWITCH SEAT HEATER/ REAR ACCESSORY POWER SUPPLY RELAY (BEHIND LEFT SIDE OF DASH) VIO WIRE YEL WIRE YEL/RED WIRE
