Wiring diagram engine performance 2.5l, with low emissions for Subaru Outback BP (2003-2006)

5 6 7 8 PNK WIRE A/T M/T AIR CONDITIONING SYSTEM BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/WHT WIRE CAMSHAFT POSITION SENSOR (LEFT FRONT SIDE OF ENGINE) CLUTCH SWITCH (ON CLUTCH PEDAL BRACKET) CRANKSHAFT POSITION SENSOR (FRONT OF ENGINE) CRUISE CONTROL SYSTEM DEFOGGER SYSTEM ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) GE (ON LEFT, RIGHT REAR A/T OF ENGINE) GE (ON LEFT, RIGHT REAR OF ENGINE) GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/YEL WIRE GRY/RED WIRE GRY/YEL WIRE HOT AT ALL TIMES IGNITION SWITCH INHIBITOR SWITCH (RIGHT SIDE OF TRANSMISSION) KNOCK SENSOR (ON TOP LEFT OF ENGINE) LOCK OFF LT GRN/RED WIRE M/T M/T A/T NCA WIRE NEUTRAL POSITION SWITCH (M/T) (ON TRANSFER CASE) ON LOCK OFF ORG/ WIRE ORG/BLU WIRE PNK WIRE PNK/LT BLU WIRE POWER STEERING OIL PRESSURE SWITCH (ON POWER STEERING OIL PUMP) RED WIRE RED/BLU WIRE RED/GRN WIRE SHORT CONNECTOR STARTING/ CHARGING SYSTEM VIO WIRE VIO/GRN WIRE VIO/WHT WIRE VIO/YEL WIRE W/ FACTORY ANTI-THEFT W/O FACTORY ANTI-THEFT WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE

5 6 7 8 PNK WIRE A/T BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE BRN/WHT WIRE ELECTRIC THROTTLE (TOP REAR OF ENGINE) ELECTRIC THROTTLE RELAY ENGINE COOLANT TEMPERATURE SENSOR, THERMOMETER (RIGHT REAR OF ENGINE) FUEL PUMP FUEL PUMP CONDENSER (SEDAN) (ABOVE LEFT REAR WHEELWELL) FUEL PUMP RELAY (BEHIND LEFT SIDE OF DASH) FUEL SUB LEVEL SENSOR FUEL LEVEL SENSOR FUEL SUB LEVEL SENSOR FUEL PUMP ASSEMBLY (ON TOP OF FUEL TANK) FUEL TEMP SENSOR FUSE 13 FUSE, FUSE 11 RELAY BOX (LEFT SIDE OF DASH) GB-8 (UNDER RIGHT FRONT SEAT) GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN ON OR START LINE END CHECK CONNECTOR LT GRN WIRE LT GRN/RED WIRE NCA WIRE ORG/ WIRE ORG/BLU WIRE PNK WIRE PNK/BLK WIRE PNK/WHT WIRE PRESSURE SENSOR RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE TUMBLE GENERATOR VALVE OPENING SENSOR (LEFT FRONT OF ENGINE) VIO WIRE VIO/GRN WIRE VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRY WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE

A/T M/T ACCELERATOR POSITION SENSOR (LEFT CENTER OF DASH) AIR FLOW METER (FRONT OF ENGINE) BLK PNK/ WIRE BLK WIRE BLK/ GRN WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/WHT WIRE BRN/WHT WIRE COMBINATION METER FUSE FUSE 5 FUSE SBF-5 FUSE/ RELAY BOX (LEFT REAR OF ENGINE COMPT) GB-3 (AT REAR OF ENGINE COMPT) GRN WIRE GRN/BLK WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES IND MALFUNCTION LT GRN WIRE MAIN FUSE BOX (LEFT SIDE OF COMPT) MICRO COMPUTER NCA WIRE OP CONNECTOR (BEHIND LEFT CENTER OF DASH) ORG/ WIRE ORG/BLU WIRE ORG/WHT WIRE PNK WIRE PNK/BLK WIRE PNK/WHT WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE SPEEDO- METER TACHO- METER TEMPERATURE GAUGE TEST MODE CONNECTOR TRANSMISSION CONTROL MODULE (BEHIND LEFT SIDE OF DASH) VEHICLE SPEED SENSOR (M/T) (ON RIGHT SIDE OF TRANSMISSION) W/ SPORT SHIFT W/O SPORT SHIFT WHT GRN/ WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE

AIR CONDITIONING SYSTEM BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/ORG WIRE BLK/PNK WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/YEL WIRE COOLING FANS SYSTEM CRUISE CONTROL SYSTEM ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) FUEL INJECTORS GE (ON LEFT, RIGHT REAR OF ENGINE) GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/BLK WIRE GRY/LT BLU WIRE GRY/ORG WIRE GRY/RED WIRE GRY/YEL WIRE HOT AT ALL TIMES INTERNAL PRESSURE SOLENOID VALVE (REAR CENTER OF VEHICLE) LEFT FRONT OXYGEN SENSOR (A/F) (LEFT REAR OF ENGINE COMPT) LT BLU WIRE LT BLU/RED WIRE LT GRN WIRE LT GRN/BLK WIRE M/T NCA WIRE ORG/ WIRE ORG/BLK WIRE ORG/WHT WIRE PNK WIRE PNK/BLK WIRE PNK/BLU WIRE PNK/GRN WIRE PURGE CONTROL SOLENOID VALVE REAR OXYGEN SENSOR (LEFT REAR OF TRANSMISSION) RED WIRE RED YEL/ WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT OXYGEN SENSOR (A/F) (RIGHT REAR OF ENGINE COMPT) SBF HOLDER (LEFT SIDE OF ENGINE COMPT) TUMBLE GENERATOR VALVE (TOP REAR OF ENGINE) IGNITION COIL, IGNITOR WHT WIRE WHT/ BLK WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/LT BLU WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE YEL/WHT WIRE
