Subaru Outback BP (2003-2006) sport shift switch Wiring diagrams
This page contains all the electrical diagrams for the component. sport shift switch, in which he is found in the car Subaru Outback BP (2003-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram sport shift switch (1 of 2)
15 14 5 OP CONNECTOR (BEHIND LEFT CENTER OF DASH)
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLK/BLU WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
BUZZER
CHECK CONNECTOR (LEFT END OF DASH)
COMBINATION METER
DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH)
DOWN UP
FUSE 16
FUSE 4 FUSE 5
FUSE/ RELAY BOX
GB-3 (AT REAR OF ENGINE COMPT)
GB-5 (UNDER FRONT OF CENTER CONSOLE)
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
IGNITION RELAY (IN RELAY BLOCK)
ILLUMINATION CONTROL CIRCUIT
INHIBITOR SWITCH (RIGHT SIDE OF TRANSMISSION)
LINE END CHECK CONNECTOR (UPPER LEFT CENTER OF DASH)
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
MAIN FUSE BOX (LEFT SIDE OF ENGINE COMPT)
ORG/BLK WIRE
ORG/BLU WIRE
PNK WIRE
PNK/BLK WIRE
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
SHIFT
SPORT SHIFT SWITCH
STOPLIGHT SWITCH (ON BRAKE PEDAL BRACKET)
TEMP IND A/T OIL
TRANSMISSION CONTROL MODULE (TCM) (BEHIND LEFT SIDE OF DASH)
U COM
VIO/GRN WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> 2.5l, a/t circuit, with low emissions with sport shift (1 of 2) -> SPORT SHIFT SWITCH
Wiring diagram sport shift switch (2 of 2)
A/T CONTROL (TRANSMISSION)
A/T OIL TEMP IND
ATF TEMPERATURE SENSOR
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMBINATION METER 9 8 10 3 11 4 6 5
DIMMER CIRCUIT
DOWN
FUSE 5 FUSE 2
GB-3 (AT REAR OF ENGINE COMPT)
GB-5 (UNDER FRONT OF CENTER CONSOLE)
GB-7 (AT FRONT LEFT SIDE OF CENTER CONSOLE)
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
IGNITION RELAY (IN RELAY BLOCK)
ILLUMINATION CONTROL CIRCUIT
INHIBITOR SWITCH (RIGHT SIDE OF TRANSMISSION)
L/C TIMING
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
MAIN FUSE BOX (LEFT SIDE OF ENGINE COMPT)
MICRO COMPUTER
NCA WIRE
OP CONNECTOR (BEHIND LEFT CENTER OF DASH)
ORG/ WIRE
ORG/BLK WIRE
ORG/BLU WIRE
PNK/BLK WIRE
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
SHIELD JOINT CONNECTOR (LEFT CENTER OF DASH)
SHIFT
SOLENOID
SOLENOID 1
SOLENOID 2
SOLENOID AWD
SOLENOID LINE PRESSURE
SOLENOID LOCK-UP
SOLENOID SPORTS SHIFT
SPORT SHIFT SWITCH
TORQUE CONVERTER TURBINE SPEED SENSOR
VEHICLE SPEED SENSOR 1 (ON RIGHT SIDE OF TRANSMISSION)
VEHICLE SPEED SENSOR 2 (ON RIGHT SIDE OF TRANSMISSION)
VIO WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> 2.5l, a/t circuit, with sport shift, without low emissions with sport shift (2 of 2) -> SPORT SHIFT SWITCH
