Subaru Outback BP (2003-2006) engine coolant temperature sensor, thermometer (on top center Wiring diagram

BLK WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE DIAGNOSIS TERMINAL ELECTRIC THROTTLE (AT CENTER REAR OF ENGINE) ENGINE COOLANT TEMPERATURE SENSOR, THERMOMETER (ON TOP CENTER GB-3 GB-5 (BEHIND CENTER OF DASH) GE-2 (TOP RIGHT OF ENGINE) GRN/BLK WIRE GRN/RED WIRE GRN/YEL WIRE HOT AT ALL TIMES INTERCOOLER WATER SPRAY SWITCH INTERCOOLER WATER SPRAY TIMER (BEHIND RIGHT SIDE OF DASH) LEFT TGV ANGLE SENSOR LINE END CONNECTOR LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE MAIN FUSE BOX (M/B) (ON LEFT SIDE OF ENGINE COMPT) NCA WIRE NEUTRAL POSITION SWITCH OF ENGINE) ORG/ WIRE ORG/WHT WIRE PRESSURE SENSOR RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RIGHT TGV ANGLE SENSOR SBF-5 FUSE TEST MODE CONNECTOR VEHICLE SPEED SENSOR (ON RIGHT SIDE OF TRANSMISSION CASE) VIO WIRE VIO/WHT WIRE WHT WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE
