Subaru Outback BP (2003-2006) clearance light ind light Wiring diagram

AUTO A/C CONTROL MODULE (BELOW CENTER OF DASH) BLK WIRE BLK/WHT WIRE BLU WIRE CIRCUIT DIMMER CLEARANCE LIGHT IND LIGHT CLOCK COMBINATION METER COMBINATION SWITCH COMPACT DISC PLAYER ILLUMINATION LIGHT DIMMER CIRCUIT DRIVER'S CONTROL CENTER DIFFERENTIAL AUTO/MANUAL SWITCH ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) FRONT ACCESSORY POWER SUPPLY SOCKET ILLUMINATION LIGHT FRONT FOG LIGHT SWITCH ILLUMINATION LIGHT FUSE 12 FUSE 13 FUSE 7 FUSE, RELAY BOX (F/B) (BEHIND LEFT SIDE OF DASH) GLOVE BOX ILLUMINATION LIGHT GRN/YEL WIRE GRY/RED WIRE HAZARD SWITCH ILLUMINATION LIGHT HEAD OFF PARK HEADLIGHT LEVELER SWITCH HOT AT ALL TIMES HOT IN ON OR START INTERCOOLER WATER SPRAY SWITCH LETTER PLATE ILLUM LIGHT IND LIGHTING SWITCH LIQUID CRYSTAL DISPLAY BACK LIGHT IND LOGO LIGHT IND MAIN FUSE BOX (M/B) (ON LEFT SIDE OF ENGINE COMPT) MICROCOMPUTER NCA WIRE ORG WHT/ WIRE ORG/WHT WIRE POINTER ILLUM LIGHT IND RADIO ILLUMINATION LIGHT RED/ WHT WIRE RED/WHT WIRE TAIL, ILLUMINATION RELAY VIO WIRE WHT ORG/ WIRE WHT RED/ WIRE WHT/ BLK WIRE WHT/RED WIRE
