Subaru Outback BH (1999-2003) parking position switch, shift lock solenoid Wiring diagram
This page shows the only wiring diagram for the component.parking position switch, shift lock solenoid, which is found in the car Subaru Outback BH (1999-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram parking position switch, shift lock solenoid (1 of 1)
