Subaru Outback BH (1999-2003) not used not used wiring diagram
This page shows the only wiring diagram for the component.not used not used, which is found in the car Subaru Outback BH (1999-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
not used not used wiring diagram (1 of 1)
ANTENNA AMPLIFIER (RIGHT SIDE OF LUGGAGE COMPT)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
BRN/WHT WIRE
DIN CORD
FUSE 2
FUSE 9
FUSE/ RELAY BOX
GRN WIRE
HOT AT ALL TIMES
HOT IN ACC, ON
LEFT FRONT DOOR SPEAKER
LEFT FRONT DOOR TWEETER
LEFT REAR DOOR SPEAKER
LEFT SPEAKER JOINT CONNECTOR
LT GRN WIRE
MAIN FUSE BOX
NCA WIRE
NOT USED NOT USED
ORG/ WIRE
PNK WIRE
POWER AMPLIFIER (CENTER OF DASH)
RADIO
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY BLOCK (BEHIND LEFT SIDE OF DASH)
RIGHT FRONT DOOR SPEAKER
RIGHT FRONT DOOR TWEETER
RIGHT REAR DOOR SPEAKER
RIGHT SPEAKER JOINT CONNECTOR
SBF HOLDER (LEFT SIDE OF ENGINE COMPT)
SBF-8 FUSE
SUB-WOOFER
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Radio circuits, with macintosh audio system -> NOT USED NOT USED
