Subaru Outback BH (1999-2003) multiple power socket relay Wiring diagram
This page shows the only wiring diagram for the component.multiple power socket relay, which is found in the car Subaru Outback BH (1999-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram multiple power socket relay (1 of 1)
2.5L
3.0L
A/T SHIFT LOCK CONTROL MODULE
ABS CONTROL MODULE
AIR CONDITIONING RELAY HOLDER
AIR CONDITIONING RELAY HOLDER MAIN FAN RELAY
AUTO A/C CONTROL MODULE
BLK WIRE
BLU WIRE
FROM BATTERY (DIAGRAM 1 OF 4)
FROM FUSE, RELAY BOX (DIAGRAM 2 OF 4)
FROM MAIN FUSE BOX (DIAGRAM 2 OF 4)
FROM MAIN FUSE BOX SBF-2 (DIAGRAM 2 OF 4)
FRONT ACCESSORY POWER SUPPLY
FUSE
FUSE 10
FUSE 16
FUSE 19
FUSE 4
FUSE/ RELAY BOX
GRN WIRE
LEFT REARVIEW MIRROR (HEATER)
LEFT VANITY MIRROR ILLUMINATION LIGHT
MOTOR RELAY (VEHICLE DYNAMIC CONTROL SYSTEM)
MULTIPLE POWER SOCKET
MULTIPLE POWER SOCKET FUSE HOLDER
MULTIPLE POWER SOCKET RELAY
NCA WIRE
POWER AMPLIFIER
RED WIRE
RED/BLK WIRE
RELAY BLOCK
RELAY BOX
REMOTE CONTROL REARVIEW MIRROR SWITCH
RIGHT REARVIEW MIRROR (HEATER)
RIGHT VANITY MIRROR ILLUMINATION LIGHT
SBF HOLDER
SBF-7 FUSE
SBF-8 FUSE
SEAT HEATER RELAY/ REAR ACCESSORY POWER SUPPLY RELAY
STOPLIGHT SWITCH
SUB FAN RELAY
SUB FAN RELAY 1 MAIN FAN RELAY
SUB FAN RELAY 2
TRAILER CONNECTOR
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
WIPER DEICER RELAY
YEL WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (4 of 4) -> MULTIPLE POWER SOCKET RELAY
