Subaru Outback BH (1999-2003) interrupt relay Wiring diagram
This page shows the only wiring diagram for the component.interrupt relay, which is found in the car Subaru Outback BH (1999-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram interrupt relay (1 of 1)
2.5L, 3.0L
A/T
A/T W/O SECURITY SYSTEM
BLK WIRE
BLK/RED WIRE
BLU WIRE
COMBINATION SWITCH
CRUISE CONTROL MODULE (A/T)
EXTERIOR LIGHTS SYSTEM (PARKING SWITCH)
FROM IGNITION RELAY (DIAGRAM 1 OF 4)
FROM MAIN FUSE BOX SBF-1 (DIAGRAM 1 OF 4)
FROM MAIN FUSE BOX, HEADLIGHT RELAYS (DIAGRAM 1 OF 4)
FRONT WIPER MOTOR FRONT WASHER MOTOR
FRONT WIPER SWITCH REAR WIPER INTERMITTENT MODULE
FUSE 14
FUSE 15
FUSE 5
FUSE 9
FUSE/ RELAY BOX
GENERATOR
GRN WIRE
IGNITION SWITCH
INHIBITOR SWITCH
INHIBITOR SWITCH STARTER INTERLOCK RELAY
INTERRUPT RELAY
LEFT FRONT CLEARANCE LIGHT RADIO
LEFT REAR COMBINATION LIGHT SEDAN WAGON
LICENSE PLATE LIGHT
M/T
M/T A/T
MAIN FUSE BOX
NCA WIRE
OFF
OFF ON
ORG/ WIRE
REAR WASHER MOTOR REAR WIPER MOTOR
RED WIRE
RIGHT FINISHER LIGHT LEFT FINISHER LIGHT
RIGHT FRONT CLEARANCE LIGHT LEFT LICENSE PLATE LIGHT
RIGHT LICENSE PLATE LIGHT
RIGHT REAR COMBINATION LIGHT
SBF-2 FUSE
SBF-4 FUSE
SEAT HEATER FUSE HOLDER
SEAT HEATER RELAY
SHORT CONNECTOR
STARTER INTERLOCK RELAY
TO AIR CONDITIONING FUSE HOLDER (DIAGRAM 4 OF 4)
TO FUSE, RELAY BOX (DIAGRAM 4 OF 4)
TO FUSE, RELAY BOX FUSE 18 (DIAGRAM 3 OF 4) ENGINE CONTROL MODULE
TO FUSE, RELAY BOX FUSE 4 (DIAGRAM 4 OF 4)
TO SBF FUSE HOLDER (DIAGRAM 4 OF 4)
TRAILER CONNECTOR
W/ SECURITY
W/ SECURITY CONNECTOR
W/O SECURITY
W/O SECURITY CONNECTOR
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
Go to component -> Power distribution circuit (2 of 4) -> INTERRUPT RELAY
