Subaru Outback BH (1999-2003) hi pass pass lo lo dimmer/ passing switch Wiring diagrams
This page contains all the electrical diagrams for the component. hi pass pass lo lo dimmer/ passing switch, in which he is found in the car Subaru Outback BH (1999-2003). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
hi pass pass lo lo dimmer/ passing switch wiring diagram (1 of 2)
2 LIGHT MODEL
26 30 2.5L 3.0L
28 31 2.5L 3.0L
29 25 3.0L 2.5L
33 27 3.0L 2.5L
4 LIGHT MODEL
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BLU/YEL WIRE
COMBINATION METER
COMBINATION SWITCH
DAYTIME RUNNING LIGHT MODULE (BEHIND CENTER OF DASH)
DAYTIME RUNNING LIGHT RELAY (IN RELAY BLOCK)
FOGLIGHT SWITCH
FRONT FOG- LIGHT DIODE (BEHIND LEFT SIDE OF DASH)
FRONT FOGLIGHT RELAY (IN A/C RELAY HOLDER)
FUSE 11
FUSE 7
FUSE 8
FUSE 9
FUSE/ RELAY BOX
GRN WIRE
GRN/RED WIRE
HI PASS PASS LO LO DIMMER/ PASSING SWITCH
HI-BEAM IND
HOT AT ALL TIMES
HOT IN ON, START
IGNITION SWITCH
INSTRUMENT CLUSTER SYSTEM (PARK BRAKE WARNING INDICATOR) PNK WIRE
LEFT FOG LIGHT
LEFT HEADLIGHT
LEFT HEADLIGHT RELAY
LEFT HEADLIGHT RIGHT HEADLIGHT
LIGHT SWITCH
MAIN FUSE BOX
OFF
ON OFF
OPTION CONNECTOR (BEHIND CENTER OF DASH)
ORG/ WIRE
PARK HEAD OFF
PARKING BRAKE SWITCH (BASE OF PARK BRAKE LEVER)
PNK (OR WIRE
PNK WIRE
RED WIRE
RED/BLU WIRE
RED/GRN (OR RED/BLU) WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT FOG LIGHT
RIGHT HEADLIGHT
RIGHT HEADLIGHT RELAY
STARTING/ CHARGING SYSTEM
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
Go to component -> Headlight circuit -> HI PASS PASS LO LO DIMMER/ PASSING SWITCH
hi pass pass lo lo dimmer/ passing switch wiring diagram (2 of 2)
A/T
ALTERNATOR
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
COMBINATION METER
COMBINATION SWITCH
DAYTIME RUNNING LIGHT CONTROL MODULE (RIGHT KICK PANEL)
DAYTIME RUNNING LIGHT DIODE (RIGHT SIDE OF DASH)
DAYTIME RUNNING LIGHT HI BEAM RELAY (RIGHT KICK PANEL)
DAYTIME RUNNING LIGHT RELAY (RIGHT KICK PANEL)
DAYTIME RUNNING LIGHT RESISTOR (RIGHT SIDE OF ENG COMPT)
FRONT FOGLIGHT DIODE (LEFT SIDE OF DASH)
FRONT FOGLIGHT RELAY (LEFT OF STEERING COLUMN)
FRONT FOGLIGHT SWITCH
FUSE 18
FUSE 7
FUSE 8
FUSE 9
FUSE/ RELAY BOX
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/WHT WIRE
HI PASS PASS LO LO DIMMER/ PASSING SWITCH
HI-BEAM IND
HOT AT ALL TIMES
HOT IN ON, START
IGNITION SWITCH
INHIBITOR SWITCH (RIGHT SIDE OF TRANSAXLE)
INSTRUMENT CLUSTER SYSTEM (CHARGE INDICATOR)
INSTRUMENT CLUSTER SYSTEM (PARK BRAKE WARNING INDICATOR)
LEFT FRONT FOG LIGHT
LEFT HEADLIGHT
LEFT HEADLIGHT RELAY
LIGHT SWITCH
MAIN FUSE BOX
OFF
ON OFF
PARK HEAD OFF
PARKING BRAKE SWITCH (BASE OF PARK BRAKE LEVER)
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RIGHT FRONT FOG LIGHT
RIGHT HEADLIGHT
RIGHT HEADLIGHT RELAY
STARTING CIRCUIT
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Headlight circuit, with drl -> HI PASS PASS LO LO DIMMER/ PASSING SWITCH
