Subaru Outback BG (1994-1999) rear defogger switch illumination light Wiring diagrams
This page contains all the electrical diagrams for the component. rear defogger switch illumination light, in which he is found in the car Subaru Outback BG (1994-1999). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
rear defogger switch illumination light wiring diagram (1 of 2)
A/T SELECTOR LEVER ILLUMINATION LIGHT
ASHTRAY ILLUMINATION LIGHT
BLK WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
BRN/RED WIRE
CD PLAYER ILLUMINATION LIGHT
COMBINATION METER
COMBINATION SWITCH
CRUISE CONTROL MAIN SWITCH ILLUMINATION LIGHT
FRONT FOG LIGHT SWITCH ILLUMINATION LIGHT
FUSE 23
FUSE 9
FUSE/ RELAY BOX
GLOVE BOX ILLUMI- NATION LIGHT
HAZARD SWITCH ILLUMINATION LIGHT
HEAD OFF PARK
HOT AT ALL TIMES
HOT IN ON, START
ILLUMINATION CONTROL MODULE (LEFT OF STEERING COLUMN)
ILLUMINATION LIGHT
LEFT SEAT HEATER SWITCH ILLUMINATION LIGHT (OUTBACK STEP ROOF MODEL)
LIGHT SWITCH
MAIN FUSE BOX
MODE CONTROL PANEL ILLUMINATION LIGHT
NCA WIRE
RADIO ILLUMINATION LIGHT
REAR DEFOGGER SWITCH ILLUMINATION LIGHT
RIGHT SEAT HEATER SWITCH ILLUMINATION LIGHT (OUTBACK STEP ROOF MODEL)
TAIL, ILLUMINATION RELAY
TCF OFF SWITCH ILLUMINATION LIGHT
WHT WIRE
WHT/GRN WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Instrument illumination circuit -> REAR DEFOGGER SWITCH ILLUMINATION LIGHT
rear defogger switch illumination light wiring diagram (2 of 2)
A/T SELECTOR LEVER ILLUMINATION LIGHT
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BRN WIRE
BRN/YEL WIRE
CD ILLUMINATION LIGHT
COMBINATION METER
COMBINATION SWITCH
COUPE
CRUISE CONTROL MAIN SWITCH ILLUMINATION LIGHT
DIODE (BEHIND LEFT SIDE OF I/P)
DOOR
FUSE 23
FUSE 25
FUSE 9
FUSE AND RELAY BOX (LEFT SIDE OF ENGINE COMPARTMENT)
FUSE BOX ILLUMINATION LIGHT
GRN WIRE
HAZARD SWITCH ILLUMINATION LIGHT
HEAD OFF PARK
HOT AT ALL TIMES
HOT IN ON AND START
ILLUMINATION CONTROL MODULE (IN CENTER CONSOLE)
LEFT FRONT DOOR SWITCH
LEFT REAR DOOR SWITCH
LIGHT SWITCH
LUGGAGE ROOM LIGHT (WAGON)
MAIN FUSE BOX (BEHIND LEFT SIDE OF DASH)
MODE CONTROL PANEL ILLUMINATION LIGHT
NCA WIRE
ORG/ WIRE
RADIO ILLUMIN- ATION LIGHT
REAR DEFOGGER SWITCH ILLUMINATION LIGHT
REAR GATE LATCH SWITCH (WAGON)
RED WIRE
RED/BLK WIRE
RIGHT FRONT DOOR SWITCH
RIGHT REAR DOOR SWITCH
ROOM LIGHT
SEDAN WAGON
SPOT LIGHT
TAIL, ILLUMINATION RELAY
TRUNK ROOM LIGHT (SEDAN)
TRUNK ROOM LIGHT SWITCH (SEDAN)
WHT WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Interior light circuit -> REAR DEFOGGER SWITCH ILLUMINATION LIGHT
