Subaru Legacy BW (2019-2024) yellow rh Wiring diagram
This page shows the only wiring diagram for the component.yellow rh, which is found in the car Subaru Legacy BW (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram yellow rh (1 of 1)
A/S CAN-H
A/S CAN-L
BLK WIRE
BLU WIRE
BRN WIRE
CAN DRIVER
CAN TRANSCEIVER
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CRUISE
DISTANCE
DRIVE CIRCUIT
EYESIGHT ASSIST MONITOR (BEHIND LEFT SIDE OF DASH)
FUSE 11
FUSE 22
FUSE 26
FUSE 6
FUSE, RELAY BOX (F/B)
GB-2
GB-2 (LEFT KICK PANEL)
GND CRU SW
GREEN
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LANE CENTERING
LANE DEPARTURE
LT BLU WIRE
LT GRN WIRE
MICROCOMPUTER
ORG/ WIRE
PNK WIRE
POWER CIRCUIT
POWER SUPPLY CIRCUIT
RED LH WIRE
RED RH WIRE
RED WIRE
RES+
ROLL CONNECTOR
SATELLITE SWITCH
SET-
STEERING COLUMN)
STEREO CAMERA
TAN WIRE
WARNING OFF IND
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YELLOW LH
YELLOW RH
Go to component -> Eyesight circuit -> YELLOW RH
