Subaru Legacy BW (2019-2024) trunk room light Wiring diagrams
This page contains all the electrical diagrams for the component. trunk room light, in which he is found in the car Subaru Legacy BW (2019-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram trunk room light (1 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DOOR
GRN WIRE
LEFT FRONT DOOR STEP LIGHT
LEFT OUTER MIRROR CONTROL MODULE
LT BLU WIRE
LT GRN WIRE
LUGGAGE ROOM LIGHT
OFF
OP CONNECTOR (LEFT APPROACH LIGHT)
OP CONNECTOR (RIGHT APPROACH LIGHT)
ORG/ WIRE
PNK WIRE
RED WIRE
RIGHT FRONT DOOR STEP LIGHT
RIGHT OUTER MIRROR CONTROL MODULE
SEDAN
TRUNK ROOM LIGHT
W/ MEMORY
W/O MEMORY
WAGON
WHT WIRE
WHT/BLK WIRE
Go to component -> Courtesy lamps circuit (2 of 3) -> TRUNK ROOM LIGHT
Wiring diagram trunk room light (2 of 2)
BLK WIRE
BLU WIRE
BLU/YEL WIRE
EYESIGHT ASSIST MONITOR
FROM FUSE 37 (DIAGRAM 5 OF 11)
FROM MAIN FUSE BOX (M/B) (DIAGRAM 11 OF 11)
FRONT RELAY CONTROL MODULE
FUSE 26
FUSE 28
FUSE 32
IMMOBILIZER ANTENNA
LEFT FRONT DOOR STEP LIGHT
LEFT OUTER MIRROR CONTROL MODULE
LEFT VANITY MIRROR LAMP
LUGGAGE ROOM LIGHT
MAIN FUSE BOX (M/B)
MIRROR HEATER RELAY
OP CONNECTOR (LEFT APPROACH LIGHT)
OP CONNECTOR (REMOTE ENGINE START CONTROL MODULE)
OP CONNECTOR (RIGHT APPROACH LIGHT)
OP CONNECTOR (TRAILER)
ORG/ WIRE
PNK WIRE
REAR VIEW MIRROR)
RED WIRE
RIGHT FRONT DOOR STEP LIGHT
RIGHT OUTER MIRROR CONTROL MODULE
RIGHT VANITY MIRROR LAMP
ROOM LIGHT
SEDAN
SPOT MAP LIGHT
TRUNK ROOM LIGHT
VIO WIRE
W/ MEMORY
W/O MEMORY
WAGON
WHT WIRE
Go to component -> Power distribution circuit (6 of 11) -> TRUNK ROOM LIGHT
