Subaru Legacy BW (2019-2024) sunroof unit Wiring diagrams
This page contains all the electrical diagrams for the component. sunroof unit, in which he is found in the car Subaru Legacy BW (2019-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram sunroof unit (1 of 3)
A/C CONTROL MODULE
BLK WIRE
CENTRAL GATEWAY CONTROL MODULE
DC/DC CONVERTER 2
FRONT ACCESSORY POWER SUPPLY SOCKET
FRONT POWER WINDOW SUB SWITCH
GB-1 (RIGHT KICK PANEL)
GRY WIRE
HAZARD SWITCH
LEFT FRONT DOOR LOCK ACTUATOR
LEFT FRONT DOOR STEP LIGHT
LEFT FRONT POWER WINDOW MOTOR
LEFT OUTER MIRROR ASSEMBLY
LEFT OUTER MIRROR CONTROL MODULE
LEFT VANITY MIRROR LIGHT
NCA WIRE
OP CONNECTOR (REAR VIEW MIRROR)
PASSENGERS DOOR LOCK SWITCH
POWER TRANSISTOR
POWER WINDOW MAIN SWITCH
REAR ACCESSORY POWER SUPPLY SOCKET (CONSOLE)
REAR VIEW MIRROR)
REMOTE CONTROL MIRROR SWITCH
RIGHT FRONT DOOR LOCK ACTUATOR
RIGHT FRONT DOOR STEP LIGHT
RIGHT FRONT POWER WINDOW MOTOR
RIGHT OUTER MIRROR ASSEMBLY
RIGHT OUTER MIRROR CONTROL MODULE
RIGHT VANITY MIRROR LIGHT
ROLL CONNECTOR
ROOM LIGHT
SEAT POSITION MEMORY SWITCH
SPOT MAP LIGHT
STEERING COLUMN)
STEERING WHEEL STEERING HEATER CONTROL MODULE
SUNROOF SWITCH (SLIDE, TILT)
SUNROOF UNIT
TELEMATICS BUTTON
TO GROUND GB-2 (DIAGRAM 5 OF 5)
USB POWER SUPPLY (CONSOLE)
W/ AUDIO AMPLIFIER
W/ BSD/ RCTA
W/ FRONT SEAT HEATER
W/ MEMORY
W/ MIRROR TURN
W/O MEMORY
WHT WIRE
Go to component -> Ground distribution circuit (4 of 5) -> SUNROOF UNIT
Wiring diagram sunroof unit (2 of 3)
2.5L
BLK WIRE
BLOWER MOTOR RELAY
BRN WIRE
COCKPIT CONTROL UNIT
DATA COMMUNICATION MODULE
DATA LINK CONNECTOR
FROM IG 1 RELAY (DIAGRAM 7 OF 11)
FUSE 13
FUSE 19
FUSE 23
FUSE 3
FUSE 8
GRN WIRE
GRY WIRE
IMMOBILIZER CONTROL MODULE
KEYLESS ENTRY CONTROL MODULE
LEFT OUTER MIRROR CONTROL MODULE
LT BLU WIRE
MAIN FUSE BOX (M/B)
OP CONNECTOR (LED LINER)
OP CONNECTOR (REAR VIEW MIRROR)
ORG/ WIRE
POWER REAR GATE CONTROL MODULE
POWER WINDOW RELAY
REAR SEAT HEATER CONTROL MODULE
REAR VIEW MIRROR)
RED WIRE
RIGHT OUTER MIRROR CONTROL MODULE
SEAT POSITION MEMORY CONTROL MODULE
STARTER CUT RELAY
STARTER RELAY
STEERING LOCK CONTROL MODULE
STOP LIGHT, BRAKE SWITCH
SUNROOF UNIT
TPMS, KEYLESS ENTRY CONTROL MODULE
W/ TELEMATICS
YEL WIRE
Go to component -> Power distribution circuit (9 of 11) -> SUNROOF UNIT
Wiring diagram sunroof unit (3 of 3)
BLK WIRE
BLU WIRE
BODY INTEGRATED UNIT
BRN WIRE
CLOSE
FUSE 19
FUSE 2
FUSE, RELAY BOX (F/B)
GB-2
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IG 1 RELAY ENERGIZED
IGN
LIN 1
MAIN FUSE BOX (M/B)
POWER DISTRIBUTION SYSTEM
POWER WINDOW CIRCUIT BREAKER
RED WIRE
SUNROOF SWITCH (SLIDE, TILT)
SUNROOF UNIT
TILT
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Power top/sunroof circuit -> SUNROOF UNIT
