Subaru Legacy BW (2019-2024) snr pwr Wiring diagram
This page shows the only wiring diagram for the component.snr pwr, which is found in the car Subaru Legacy BW (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram snr pwr (1 of 1)
A/S CAN-H
A/S CAN-L
B-CAN H
B-CAN L
BLK WIRE
BLU WIRE
BRN WIRE
CAN DRIVER
CIRCUIT
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DOWN SWITCH
DRIVE
ECU GND
FUSE 16
FUSE 6
FUSE, RELAY BOX (F/B)
GB-2
GB-4
GRN WIRE
GRY WIRE
HOT IN ON OR START
I/SET SWITCH
IGN
LEFT CORNER SONAR SENSOR
LEFT INNER SONAR SENSOR
MICROCOMPUTER
ORG/ WIRE
RAB CONTROL MODULE (UNDER DRIVER'S SEAT)
RED WIRE
RED/WHT WIRE
RIGHT CORNER SONAR SENSOR
RIGHT INNER SONAR SENSOR
RLC
ROLL CONNECTOR
RRC+
SHIELD
SNR GND
SNR PWR
SPEAKER
STEERING COLUMN)
STEERING SWITCH
TAN WIRE
TFT SW
UP SWITCH
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Reverse automatic braking system circuit -> SNR PWR
