Subaru Legacy BW (2019-2024) pocket light Wiring diagram
This page shows the only wiring diagram for the component.pocket light, which is found in the car Subaru Legacy BW (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pocket light (1 of 1)
B-CAN H
B-CAN L
BLK WIRE
BLU WIRE
BRN WIRE
CD/DVD DECK
COCKPIT CONTROL UNIT
COMPUTER DATA LINES SYSTEM
EPB CONTROL SWITCH
FUSE, RELAY BOX (F/B)
GB-2
GRN WIRE
GRY WIRE
HAZARD SWITCH
ILLUMINATION
KEYLESS ACCESS CONTROL MODULE
LT GRN WIRE
NCA WIRE
OPTION CONNECTOR (FOG LIGHT SWITCH)
PASSENGERS DOOR LOCK SWITCH
POCKET LIGHT
PUSH BUTTON IGNITION SWITCH
RED WIRE
SEDAN
SUNROOF SWITCH (SLIDE, TILT)
SWIL
TAN WIRE
TELEMATICS BUTTON
VIEW BUTTON
VIO WIRE
W/ SUNROOF
W/ TELEMATICS
Go to component -> Instrument illumination circuit (3 of 3) -> POCKET LIGHT
