Subaru Legacy BW (2019-2024) one step Wiring diagram
This page shows the only wiring diagram for the component.one step, which is found in the car Subaru Legacy BW (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram one step (1 of 1)
ACCESSORY RELAY
BLK WIRE
BLU WIRE
DIMMER
ELEMENT
FUSE 35
FUSE 9
FUSE, RELAY BOX (F/B)
GB-1
GB-2
HOT AT ALL TIMES
HOT W/ ACCESSORY RELAY-1 ENERGIZED
MAIN FUSE BOX (M/B)
NCA WIRE
ONE STEP
RED WIRE
ROLL CONNECTOR
STEERING COLUMN)
STEERING HEATER CONTROL MODULE
STEERING HEATER SWITCH
STEERING WHEEL)
THERMISTOR
THERMOSTAT
VIO WIRE
WHT WIRE
Go to component -> Heated steering wheel circuit -> ONE STEP
