Subaru Legacy BW (2019-2024) mirror heater Wiring diagrams
This page contains all the electrical diagrams for the component. mirror heater, in which he is found in the car Subaru Legacy BW (2019-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram mirror heater (1 of 2)
B-CAN H
B-CAN L
B-CAN_H
B-CAN_L
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
FRONT RELAY CONTROL MODULE
FUSE 10
FUSE 26
FUSE 32
FUSE 33
FUSE 40
FUSE, RELAY BOX (F/B)
GB-1 (RIGHT KICK PANEL)
GB-2 (LEFT KICK PANEL)
GB-3
GG-1
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ MB-IG RELAY ENERGIZED
HTR
LEFT OUTER MIRROR ASSEMBLY
LEFT OUTER MIRROR CONTROL MODULE
MAIN FUSE BOX (M/B)
MIRROR HEATER
MIRROR HEATER RELAY
NOISE SUPPRESSOR
ORG/ WIRE
PNK WIRE
R-FOG
REAR DEFOGGER
REAR DEFOGGER RELAY
RED WIRE
RIGHT OUTER MIRROR ASSEMBLY
RIGHT OUTER MIRROR CONTROL MODULE
SEDAN
VIO WIRE
W/ MEMORY
W/O MEMORY
WAGON
WHT WIRE
Go to component -> Mirror heater & rear defogger circuit -> MIRROR HEATER
Wiring diagram mirror heater (2 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
CHANGE OVER SWITCH
DEFOGGER SYSTEM
DOOR LOCKS SYSTEM
FUSE 17
FUSE, RELAY BOX (F/B)
GB-2
GRN WIRE
GRY WIRE
HOT W/ ACCESSORY RELAY 2 ENERGIZED
LEFT OUTER MIRROR ASSEMBLY
LOCK
LT BLU WIRE
LT GRN WIRE
MIRROR HEATER
NAVIGATION SYSTEM
PNK WIRE
RED WIRE
REMOTE CONTROL MIRROR SWITCH
REMOTE CONTROL SWITCH
RIGHT OUTER MIRROR ASSEMBLY
TAN WIRE
UNLOCK
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Power mirror circuit -> MIRROR HEATER
