Subaru Legacy BW (2019-2024) key illumination Wiring diagrams
This page contains all the electrical diagrams for the component. key illumination, in which he is found in the car Subaru Legacy BW (2019-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram key illumination (1 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
DOOR
FUSE 26
FUSE, RELAY BOX (F/B)
GRN WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
IMMOBILIZER ANTENNA (W/O PUSH BUTTON START) (STEERING COLUMN)
KEY ILLUMINATION
LEFT FRONT DOOR SWITCH
LEFT REAR DOOR SWITCH
LEFT VANITY MIRROR LAMP
LT BLU WIRE
LT GRN WIRE
OFF
ORG/ WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
RIGHT VANITY MIRROR LAMP
ROOM LIGHT
SPOT MAP LIGHT
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (1 of 3) -> KEY ILLUMINATION
Wiring diagram key illumination (2 of 2)
2.5L
BLK WIRE
BLU WIRE
BODY INTEGRATED UNIT
BRN WIRE
CAN TRANSCEIVER
CENTER KEYLESS ACCESS INTERIOR ANTENNA
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DOOR LOCK BACKUP UNIT
DRIVE CIRCUIT
FRONT KEYLESS ACCESS INTERIOR ANTENNA
FUSE 13
FUSE 30
FUSE 36
FUSE 37
FUSE 5
FUSE 6
FUSE, RELAY BOX (F/B)
GB-2
GB-2 (LEFT KICK PANEL)
GRN WIRE
GRY WIRE
HIGH SPEED
HOT AT ALL TIMES
HOT W/ IG 1 RELAY ENERGIZED
HOT W/ IG 2 RELAY ENERGIZED
IMMOBILIZER ANTENNA (W/O PUSH BUTTON START) (STEERING COLUMN)
IMMOBILIZER CONTROL MODULE
KEY ILLUMINATION
KEY WARNING SWITCH
KEYLESS ACCESS CONTROL MODULE (LEFT SIDE OF DASH)
LT BLU WIRE
LT GRN WIRE
LUGGAGE COMPT FLOOR)
MICRO COMPUTER
ORG/ WIRE
PNK WIRE
POWER SUPPLY CIRCUIT
REAR KEYLESS ACCESS INTERIOR ANTENNA
RED WIRE
SECURITY IND
STEERING COLUMN)
STEERING LOCK CONTROL MODULE
VIO WIRE
W/ ID CODE BOX
W/ IMMOBILIZER CONTROL MODULE
W/O ID CODE BOX
W/O IMMOBILIZER CONTROL MODULE
WHT WIRE
YEL WIRE
Go to component -> Immobilizer circuit -> KEY ILLUMINATION
