Subaru Legacy BW (2019-2024) can transceiver driver Wiring diagram
This page shows the only wiring diagram for the component.can transceiver driver, which is found in the car Subaru Legacy BW (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram can transceiver driver (1 of 1)
ABS IND.
AIR BAG IND
AMBIENT SENSOR
BLK WIRE
BLU WIRE
BRN WIRE
CAN TRANSCEIVER DRIVER
CHARGE IND
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DIAL PLATE ILLUMINATION LIGHT
DRIVE CIRCUIT
DRIVE CIRCUIT LIGHT CONTROL
DRIVER'S SEAT BELT IND
ENGINE COOLANT TEMP. GAUGE
EPB ON IND
FRONT FOG LIGHT IND
FUEL GAUGE
FUEL LEVEL SENSOR
FUEL PUMP ASSEMBLY
FUEL SUB LEVEL SENSOR
FUSE 37
FUSE 6
FUSE, RELAY BOX (F/B)
GB-2
GRN WIRE
GRY WIRE
HI-BEAM IND
HOT AT ALL TIMES
HOT W/ IG 2 RELAY ENERGIZED
IGN
INDICATOR NEEDLE ILLUMINATION LIGHT
LEFT TURN SIG
LIGHTING IND
LOW FUEL LEVEL IND
LT BLU WIRE
LT GRN WIRE
MALFUNCTION IND
MICROCOMPUTER
NCA WIRE
OIL PRESSURE IND
OIL PRESSURE SWITCH
ORG/ WIRE
PARKING BRAKE/ BRAKE FLUID LEVEL IND
PNK WIRE
PRE-COLLISION BRAKE OFF IND
RED WIRE
RIGHT SIDE OF FRONT GRILLE)
RIGHT TURN SIG
SPEEDOMETER
SUPPLY CIRCUIT/
TACHOMETER
TAN WIRE
TFT BACK LIGHT
TIRE INFLATION PRESSURE IND
TO GREEN/YELLOW LED DIMMING CIRCUIT (DIAGRAM 3 OF 3)
TRANSMISSIONS SYSTEM
TRIP SWITCH
VDC OFF
VDC WARNING/ VDC OPERATION IND
VIO WIRE
WARNING SYSTEMS
WHT WIRE
YEL WIRE
Go to component -> Instrument cluster circuit (1 of 3) -> CAN TRANSCEIVER DRIVER
