Exterior lamps circuit for Subaru Legacy BN/BS (2014-2017)

AUTO BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/YEL WIRE BODY INTEGRATED UNIT BRN WIRE BRN/WHT WIRE COMBINATION SWITCH COMPUTER DATA LINES SYSTEM FUSE 14 FUSE 15 FUSE 19 FUSE 4 FUSE, RELAY BOX (F/B) GB-1 GB-3 GRN WIRE GRN/WHT WIRE GRY WIRE HAZARD SWITCH HOT AT ALL TIMES LEFT OUTER MIRROR ASSEMBLY LIGHTING SWITCH MAIN FUSE BOX (M/B) OFF ORG/ WIRE PNK/BLK WIRE POWER REAR GATE CONTROL MODULE RED WIRE RED/GRN WIRE RELAY ENERGIZED RIGHT OUTER MIRROR ASSEMBLY STEREO CAMERA TAIL, ILLUMINATION RELAY TURN SIGNAL SWITCH VIO WIRE W/ EYESIGHT WHT WIRE WHT/BLK WIRE

BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/YEL WIRE BLU WIRE BLU/YEL WIRE BRN/WHT WIRE CLEARANCE COMBINATION METER COMPUTER DATA LINES SYSTEM DRIVER CIRCUIT EXCEPT HALOGEN HALOGEN SEDAN WAGON FUSE, RELAY BOX (F/B) GB-3 GB-4 GB-6 (LEFT KICK PANEL) HIGH SPEED CAN TRANSCEIVER LEFT LEFT FRONT COMBINATION LIGHT LEFT LICENSE PLATE LIGHT LT BLU WIRE MICRO COMPUTER POWER SUPPLY CIRCUIT RED WIRE RED/GRN WIRE RIGHT RIGHT FRONT COMBINATION LIGHT RIGHT LICENSE PLATE LIGHT SIDE MARKER TURN IND TURN SIG VIO WIRE
