Subaru Legacy BN/BS (2014-2017) switch illum. Wiring diagram
This page shows the only wiring diagram for the component.switch illum., which is found in the car Subaru Legacy BN/BS (2014-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram switch illum. (1 of 1)
BLK WIRE
BLU WIRE
DOWN
FRONT POWER WINDOW SUB SWITCH
GB-1
GRN WIRE
GRN/YEL WIRE
GRY WIRE
LEFT REAR POWER WINDOW MOTOR
LEFT REAR POWER WINDOW SWITCH
LIGHT
OFF
ORG/ WIRE
PNK WIRE
POWER WINDOW CONTROLLER
RED WIRE
RIGHT FRONT POWER WINDOW MOTOR (MIDDLE OF RIGHT FRONT DOOR)
RIGHT REAR POWER WINDOW MOTOR
RIGHT REAR POWER WINDOW SWITCH
SWITCH ILLUM.
VIO WIRE
YEL WIRE
Go to component -> Power windows circuit, w/ driver"s & passenger"s seat auto reverse function (2 of 2) -> SWITCH ILLUM.
