Subaru Legacy BN/BS (2014-2017) right tumble generator valve actuator Wiring diagram

BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/GRN WIRE BRN/WHT WIRE BRN/YEL WIRE CRANKSHAFT POSITION SENSOR ENGINE CONTROL MODULE (RIGHT REAR OF ENGINE COMPT) FRONT OXYGEN (A/F) SENSOR GE-1 GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE LEFT INTAKE CAMSHAFT POSITION SENSOR LT GRN WIRE PNK WIRE PNK/BLK WIRE REAR OXYGEN SENSOR RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RIGHT INTAKE CAMSHAFT POSITION SENSOR RIGHT TUMBLE GENERATOR VALVE ACTUATOR VIO WIRE WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL/RED WIRE
