Subaru Legacy BM/BR facelift (2012-2014) warning systems computer data lines system Wiring diagram
This page shows the only wiring diagram for the component.warning systems computer data lines system, which is found in the car Subaru Legacy BM/BR facelift (2012-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram warning systems computer data lines system (1 of 1)
AIR BAG CONTROL MODULE (UNDER CENTER CONSOLE)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S AIR BAG MODULE (IN STEERING WHEEL)
FUSE 25
FUSE 5
FUSE BLOCK (F/B)
G-01
GRN WIRE
GRN/YEL WIRE
HOT IN ON OR START
LEFT CURTAIN AIR BAG MODULE (LEFT "C" PILLAR)
LEFT CURTAIN AIR BAG SENSOR (LEFT "C" PILLAR)
LEFT FRONT DOOR IMPACT SENSOR (DRIVER'S DOOR)
LEFT FRONT SUB SENSOR (BEHIND LEFT SIDE OF FRONT BUMPER)
LEFT LAP SEAT BELT PRETENSIONER
LEFT PRETENSIONER (BASE OF LEFT "B" PILLAR)
LEFT SIDE AIR BAG MODULE (LEFT SIDE OF DRIVER'S SEAT BACK)
LEFT SIDE AIR BAG SENSOR (LEFT "B" PILLAR)
NCA WIRE
PASSENGER'S AIR BAG MODULE (RIGHT SIDE OF DASH)
PNK WIRE
RED WIRE
RED/WHT WIRE
ROLL CONNECTOR (LEFT SIDE OF DASH)
VIO WIRE
VIO/RED WIRE
VIO/WHT WIRE
WARNING SYSTEMS COMPUTER DATA LINES SYSTEM
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/PNK WIRE
YEL/RED WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Supplemental restraints circuit (1 of 2) -> WARNING SYSTEMS COMPUTER DATA LINES SYSTEM
