Subaru Legacy BM/BR facelift (2012-2014) turbo secondary speed speed sensor sensor Wiring diagram
This page shows the only wiring diagram for the component.turbo secondary speed speed sensor sensor, which is found in the car Subaru Legacy BM/BR facelift (2012-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram turbo secondary speed speed sensor sensor (1 of 1)
AUDIO
AUDIO CONNECTOR
AUXILIARY INPUT TERMINAL
BATTERY
BLK WIRE
BLK/BLU WIRE
BLK/PNK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/RED WIRE
BRN WIRE
BUTTON
CRANKSHAFT POSITION SENSOR SHIELD
CVT
DATA LINK CONNECTOR
ELECTRONIC THROTTLE CONTROL SHIELD
FRONT OXYGEN (A/F) SENSOR SHIELD
FUEL PUMP ASSEMBLY
GB-11 (OUTBACK) (RIGHT TOP OF REAR GATE)
GB-7 (SEDAN: CENTER FRONT OF LUGGAGE COMPT) (WAGON: RIGHT QUARTERPANEL)
GB-8 (BASE OF RIGHT "B" PILLAR)
GE-1 (2.5L)
GR (LEFT SIDE OF CENTER CONSOLE)
HIGH MOUNTED REAR STOP LIGHT
KNOCK SENSOR SHIELD
LEFT REAR FINISHER LIGHT (BACKUP LIGHT)
LEFT REAR FINISHER RIGHT LIGHT REAR (TAIL COMBINATION LIGHT) LIGHT
LEFT RIGHT REAR REAR FINISHER FINISHER LIGHT LIGHT (TAIL (BACKUP LIGHT) LIGHT)
LICENSE REAR WIPER PLATE DEFOGGER MOTOR LIGHT
LUGGAGE ROOM LIGHT
NAVIGATION UNIT
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
PNK WIRE
PRIMARY SPEED INHIBITOR SENSOR SWITCH
REAR LOCK BUTTON, REAR GATE OPENER BUTTON
REAR OXYGEN SENSOR SHIELD
REARVIEW CAMERA SHIELD
RED WIRE
RIGHT LEFT LICENSE LICENSE PLATE PLATE LIGHT LIGHT
RIGHT REAR FINISHER TRUNK LIGHT LID LOCK (TAIL ACTUATOR LIGHT), SWITCH
RIGHT REAR REAR GATE FINISHER LOCK LIGHT ACTUATOR (TAIL, LATCH LIGHT) SWITCH
RIGHT SEAT HEATER
SEDAN
TCM
TURBO SECONDARY SPEED SPEED SENSOR SENSOR
W/ NORMAL AUDIO
W/ PREMIUM AUDIO
W/ PUSH
WAGON
YEL GRN/ WIRE
YEL WIRE
Go to component -> Ground distribution circuit (4 of 4) -> TURBO SECONDARY SPEED SPEED SENSOR SENSOR
