Subaru Legacy BM/BR facelift (2012-2014) right side right front tweeter door speaker Wiring diagrams
This page contains all the electrical diagrams for the component. right side right front tweeter door speaker, in which he is found in the car Subaru Legacy BM/BR facelift (2012-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right side right front tweeter door speaker (1 of 2)
ANTENNA AMPLIFIER (LEFT "C" PILLAR)
ANTENNA AMPLIFIER (LEFT "D" PILLAR)
AUDIO CONNECTOR
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLU WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BODY INTEGRATED UNIT (CENTER OF DASH)
BRN/WHT WIRE
FUSE (F/B) (LEFT KICK PANEL)
FUSE 10
FUSE 6 (LEFT SIDE OF ENGINE COMPT)
FUSE/ RELAY BOX
GR (LEFT SIDE OF CENTER CONSOLE)
GRN WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC
LEFT FRONT DOOR SPEAKER
LEFT REAR DOOR SPEAKER
LEFT SIDE TWEETER
MAIN FUSE BOX (M/B)
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT REAR DOOR SPEAKER
RIGHT SIDE RIGHT FRONT TWEETER DOOR SPEAKER
SEDAN
VIO WIRE
WAGON
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Radio provision circuit -> RIGHT SIDE RIGHT FRONT TWEETER DOOR SPEAKER
Wiring diagram right side right front tweeter door speaker (2 of 2)
ANTENNA AMPLIFIER (LEFT "C" PILLAR)
ANTENNA AMPLIFIER (LEFT "D" PILLAR)
AUDIO
AUXILIARY INPUT TERMINAL
AUXILIARY INPUT TERMINAL (W/ USB)
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BODY INTEGRATED UNIT (CENTER OF DASH)
BRN/WHT WIRE
FUSE (F/B) (LEFT KICK PANEL)
FUSE 10
FUSE/ RELAY BOX
GB-5 (RIGHT KICK PANEL)
GR (LEFT SIDE OF CENTER CONSOLE)
GRN WIRE
GRN/WHT WIRE
GRY WIRE
HOOK OFF
HOOK ON
HOT AT ALL TIMES
HOT AT ALL TIMES MAIN FUSE FUSE BOX (M/B) (LEFT SIDE OF ENGINE COMPT)
HOT IN ON OR ACC
LEFT FRONT DOOR SPEAKER
LEFT REAR DOOR SPEAKER
LEFT SIDE TWEETER
MODE
NCA WIRE
ORG/WHT WIRE
OVERHEAD CONSOLE (HANDSFREE MICROPHONE)
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT REAR DOOR SPEAKER
RIGHT SIDE RIGHT FRONT TWEETER DOOR SPEAKER
ROLL CONNECTOR (LEFT SIDE OF DASH)
SATELLITE SWITCH
SEDAN
SEEK
SEEK DOWN
TALK
VIO WIRE
VIO/WHT WIRE
VOL (-)
WAGON
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Standard radio circuit, except base -> RIGHT SIDE RIGHT FRONT TWEETER DOOR SPEAKER
